Product Description
Carvin TRX3900F Pair Of 3.5" Column Array Speakers With Fly Points
OVERVIEW
The TRx3900F Column Array is a high output, easy to carry sound reinforcement loudspeaker providing enhanced coverage with superb fidelity. Exclusively equipped with 9 Carvin Audio 3.5-inch transducers, it’s designed for all genres of music and venues, ranging from small to large events. The Constant Delivery Dispersion “CDD™” projects to the rear of the venue while averaging levels up front and its wide 120º dispersion covers larger audiences. The 10º vertical dispersion substantially minimizes feedback in reverberant environments. The TRx3900F power is supplied by the TRx3118A subwoofer delivering 1000W, 500W into each TRx3900F, or by your own amplifier system. The tour-grade enclosure features multi-ply hardwood for the integrity of the cabinet while the DuraTec™ finish, a polyurethane outer skin, provides UV and moisture protection. Projecting far into your audience, the TRx3900F delivers the most pleasant, unfatigued listening experience, and offers high intelligibility from a compact column
TRx3900F-Pair Features:
»Two column array loudspeakers
»High output column array
»Premium Carvin Audio 3.5-Inch transducers
»Fly Points - 8 M10-1.5 Thread
»CDD™ Constant Delivery Dispersion
»Wide 120º Horizontal Coverage
»Lightweight – easy to carry, 23 lbs. each
»Includes one 12ga twist lock connecting cable
»Includes SS7 connecting pole set
»Optional Carrying Bag - CB3900
TRx3900F Specifications:
CONFIGURATION
»System Design: Column Array, Passive
»CDD™Constant Delivery Dispersion
»Frequency Response: 110Hz – 18kHz
»Crossover Required: 110Hz 24dB/Oct HI PASS
»Maximum SPL: 126dB continuous, 129dB peak
»Fly-Points: 8 M10-1.5 Thread
»Power Handling: 200W continuous, 800W peak
»Impedance: 8Ω
»Connectors: 2 2-Conductor Twist Lock, IN-THRU
TRANSDUCERS
»Manufacture: CARVIN AUDIO - PS3.5-8
»Transducers: 9 x 3.5-Inch
ENCLOSURE
»Horizontal/Vertical Dispersion: 120°/10°
»Construction Material: Multi-Ply Hardwood
»Finish: DuraTec™ polyurethane
»Grill: Black powder coated steel with cloth backing
»Enclosure Protection: Moisture/UV
»Transport: 1 recessed handle
»Standard Pole Mount: 1 3/8-in cup
»Dimensions (W x D x H): 5”W x 5.5”D x 35”H
»Weight: 23 lbs. each column
