Product Description
Blizzard Wink LED moving head fixture
Wink is a powerful LED moving head fixture that comes loaded with features such as a high-output 60W 4-in-1 RGBW LED in the center with 5-45° motorized zoom for exceptionally bright wide/narrow beams, plus a 4* segment (pixel mappable) LED ring with a total of 8x 0.5W RGB LEDs for extra cool eye candy effects. Users can also shake things up with Wink’s blazing fast 540°/270° pan and tilt, or even mind-blowing unlimited movement thanks to its incredible infinite pan and tilt rotating abilities. This fixture offers 2 auto modes, 2 sound active modes, multiple color presets, virtual color wheel effects, 4-button TFT LCD display, 3-pin DMX In/Out, powerCON™ compatible power In/Out, and a single ¼ turn omega mounting bracket. And of course, it is backed by Blizzard’s 2-year warranty!
Main Features:
• 1* 60W RGBW high-output 4-in-1 LED
• 4-segment RGB colored ring with 8* 0.5W RGB 3-in-1 LEDs
• Individual pixel and LED ring control
• 5-45 degree zoomable beam angle
• 540°/270° tilt + infinite pan and tilt
• Fast Pan/tilt motors with 16-bit resolution
• Built-in auto and sound active programs
• Multiple static color presets and virtual color wheel
• Variable electronic dimming & strobe effects (1-20Hz)
• Flicker-free constant-current LED driver
• 3-pin male input and 3-pin female output
• PowerCON™ compatible AC power In/Out connectors
• Protocol: USITT DMX-512
• 19/26/35-channel DMX modes
• 2.4 inch TFT color LCD display panel with 4x touch sensitive buttons
What's in the box:
-
Wink LED moving head fixture
-
Power cord
-
Omega mounting bracket
-
User manual
Specifications:
Optical: 1x 60W RGBW 4-in-1 LED + 8* 0.5W RGB 3-in-1 LEDs (Ring) Beam Angle: 5°- 45° Luminous Intensity: 6,517 Lux @ 2.5m (5°), 425 Lux @ 2.5m (45°), 1,700 Lux @ 5m (5°), 130 Lux @ 5m (45°)
Weight + Dimensions: Width: 8.3” (210 mm) Depth: 6.5” (164 mm) Height: 12.1” (306.6 mm) Weight: 12.5 lbs. (5.7 kg)
Control Protocol: USITT DMX-512 19/26/35-channel DMX modes Standalone, master/slave, auto, sound active 3-pin XLR In/Out connections 4-button LCD control panel
Power + Current: 100-240VAC, 50-60 Hz Power Consumption: 110W, 1.44A, PF: .66
Movement: Pan: 540 degree (8-16 bit resolution) Tilt: 270 degree (8-16 bit resolution) Infinite pan and tilt
Optional road case available: Blizzard Wink Case 4x Fixture Road Case
