Product Description
Blizzard NovaStar H2 2 Rack Space Processor/Splicer
H Series is NovaStar's flagship all-in-one video splicing processor, designed specifically for fine-pitch LED applications. It is the first All-in-One splicer and controller in the industry, which greatly simplifies system integration. With the leading image processing technology in the industry, H series can give you an astonishing visual effect, truly making it the perfect solution for fine-pitch LED applications.
H2 offers a modular plug-in design, with a variety of connector modules available. It comes with the control card and power supply. A minimum of 1 additional input card, and 1 output card is required for full functionality.
Available Cards | Description |
H_4xDVI | 4x DVI Input Card |
H_4xHDMI | 4x HDMI Input Card |
H_1xHDMI2.0 | 1x HDMI2.0 Input Card |
H_1xHDMI2.0+1xDP1.2 | 1x HDMI2.0 + 1x DP1.2 Input Card |
H_2xRJ45 IP | 2x RJ45 IP Camera Input Card |
H_4x3G SDI | 4x 3G-SDI Input Card |
H_12G SDI Input Card | 1x 12G SDI Input Card |
H_2xCVBS+2xVGA | 2x CVBS + 2x VGA Input Card |
H_4xVGA | 4x VGA Input Card |
H_16xRJ45+2xFiber | 16x Ethernet Output Port and 2x Optical Ports |
H_2xRJ45+1xHDMI1.3 | 2x Ethernet and 1x HDMI1.3 for Monitoring |
H_20xRJ45 | 20x Ethernet Port Output Card |
H_800W | H Series Power Module (optional backup) |
Specs
- Rack space: 2U
- Minimum cards = 1 input, 1 output
- Input cards: 4 max.
- Input channels: 16 max.
- Output cards: 2
- Load capacity (4K card): 26m pixels
- Max. layers: 32
In the Box
- Power cord
- RJ45 Ethernet cable
- Grounding cable
- HDMI cable
- Quick start guide
- Certificate of approval
- Safety manual
Power
- 100-240VAC, 50/60Hz
- Power consumption: 210W
- 10A-5A
- Backup PS: optional
Warranty
- 2-year limited warranty
Dims & Weight
- 19" L x 3.5" W x 18" H
- 34.4 lbs
