Product Description
Blizzard Nexys WW Interlocking Warm White LED Effects Light
Overview
Modular Innovation
Nexys™ WW is 1 of 3 modular LED fixtures in the Nexys™ Series, designed with unique interlocking housings. These lights can connect in any orientation: horizontally, vertically, or diagonally to form captivating visual arrays. This specific model boasts a 80W LED with a 10° Fresnel lens for a sharp warm white beam. Additionally, it features an outer 6-pixel RGB diffused ring and an inner 6-pixel RGB backlight for enhanced visual effects.
Loaded With Features
It offers smooth dimming, strobe, built-in programs, and individual control of each of its 6 inner, and 6 outer pixel ring groups. Then for ease of use and seamless integration into any application, all Nexys™ Series fixtures come with dual mounting brackets, plus an Omega bracket with quick-lock quarter turn fasteners (clamp not included), a 4-button LCD control menu, 5-pin DMX in/out, and powerCON-TRUE1 compatible in/out connections.
Buildable Design
Dream it up and build it out. Nexys WW is 1 of 3 modular LED fixtures capable of interlocking with one another in any direction– horizontal, vertical or diagonal – thanks to its unique hexagonal shape.
Features
- 1x 80W Warm White LED (3200K) w/Fresnel lens
- 36x SMD 5050 RGB 50mW LEDs (outer ring)
- 18x SMD 5050 RGB 50mW (backlight)
- LED ring group pixels (outer: 6x6, inner: 6x3)
- Smooth dimming (0-100% )
- Warm white beam + RGB diffused ring & backlight
- Built-in programs and manual color mixing
- 5-pin DMX in/out connections
- powerCON™ TRUE1 compatible power in/out
- 2x mounting + 1x quarter turn fastening Omega bracket
- Interlocking housing design to join multiple fixtures
- Heavy-duty aluminum enclosure
Specifications
Optical
- 80W flicker-free WW LED (3200K)
- 36x and 18x SMD 5050 RGB 50mW LEDs (outer and backlight)
- 10° beam angle
- 6,107 Lux @ 2.5M
- 1,354 Lux @ 5M
Control
- Protocol: USITT DMX-512
- 5-pin DMX in/out
- 6/11/42-channel DMX
- 4-button menu with LCD display
- DMX512, M/S, auto mode
Power & Current
- 100-250VAC, 50-60 Hz
- Consumption: 90W, 1.21A, PF: .64
- PowerCON® TRUE1-compatible in/out
Dimensions
- 17.9" x 4.9" x 6.8"
- 5.3 lbs
