Product Description
Blizzard DMX-500 500 foot Spool 22 AWG DMX Cable
Cool Cable lighting control cables are true high quality DMX cables with exceptionally durable and flexible construction. They meet the USITT standards for DMX512 cable specifications—100 ohm characteristic impedance, low capacitance, and double (foil and braid) shield. Unlike conventional cables that are not intended for data transmission, Cool Cable DMX cables offer reliable data transfer through its data-specific design, and wire that is wrapped 5 times tighter than any traditional microphone cable. In addition, Cool Cable DMX cables feature an extra flexible jacket material that is tough, abrasion-resistant, and remains flexible in hot or cold temperature environments.
This 500 ft spool of raw Blizzard Cool Cable DMX cable is ultra-flexible 22-gauge custom-manufactured cable that comes with a lifetime warranty against defects.
Features
• Double shield (foil and braid)
• 100 ohm characteristic impedance
• Low capacitance
• Conductors: 2
• High quality true DMX cable
Specs
• Conductor gauge: 0.34mm²
• Conductor material: Oxygen free copper wire
• Conductor stranding: 7*Φ0.20mm
• Conductor diameter: Φ0.20mm
• Conductor twists/M: 100 conductor twists/M • Lay direction: left
• Insulation material: PE
• Insulation diameter: Φ1.35mm
• Wire pair color: red+white • Outer shield: (braid and foil) AL+PP+braid (0.12mm*64 tinned copper)
• Outer jacket material: PVC • Overall nominal cable diameter: Φ6mm
• Operating Temperature Range: -30°~70° • Bulk Cable Weight: 1.79kg/PC
• Minimum Bend Radius (Install): ≥120mm • Nominal Characteristic Impedance: 100ohm
• Nominal Capacitance Conductor to Conductor @ 1KHz: 63PF/m
• Nominal Cap Cond. To Other Cond. & Shield @ 1KHz: 105PF/m
• Nominal Velocity of Propagation: 66%
• Nominal Delay: 1.6 Nanoseconds per foot
• Nominal Conductor DC Resistance @ 20°C: ≤0.098ohm/m
• Individual Pair Nominal Shield DC Resistance @ 20°C: ≤0.026ohm/m
• Nominal Attenuation: 0.6 (@ 1 MH z) dB/100 ft
• Max Recommended Current @ 25°C: 2.1 Amps per conductor
