Product Description
Ayrton AY012650 Domino-TC 1,000W LED IP65 Profile, 6 to 60 Degree
Overview
A recent addition to AYRTON's IP65 multi-function luminaire family, the DOMINO PROFILE is engineered for rigorous outdoor applications, combining remarkable light power with comprehensive standard features.
The DOMINO PROFILE S is equipped with an entirely new 1000 W monochromatic, high-efficiency LED emitter calibrated at 8000 K. This luminaire delivers potent metallic white light, boasting an impressive output of 51,000 lumens at a color temperature of 7000 K during continuous operation. In contrast, the DOMINO PROFILE TC is tailored for scenarios demanding impeccable color rendition, boasting a C.R.I. greater than 90 and exceptionally high TM30 readings at a color temperature of 6000 Kelvin.
Designed around the exceptional optics of the HURACÁN PROFILE, this luminaire is purpose-built to achieve an optimal balance between resolution, performance, and efficiency. These optics yield a consistently even, flat beam devoid of hotspots and ensure pristine reproduction of high-definition images. With a 178 mm frontal lens and a proprietary optical system employing 13 lenses, it offers a 10:1 zoom ratio and an adjustable zoom range spanning from 6° to 60°.
Features
- 1,000 W - 7000 K Domino Profile S
- Lumens 51,000 Domino Profile S
- Beam Aperture 6° to 60°
- Front Lens 178 mm
Specifications
- OPTICS:
- 13-element 10:1 zoom high-resolution optic system
- Beam aperture: 6° to 60°
- Fast motorized linear zoom
- Tempered anti-reflective coated lenses
- 178 mm frontal lens for greater performance
- LIGHT SOURCE:
- Domino Profile TC:
- 56,000 lumens 7000 K white light engine
- Total luminaire output: up to 36,400 lumens
- Color temperature output: 6500 K
- CRI: greater than 90
- Rated life (L70): up to 40,000 hours
- Flicker-free source management suitable for TV applications and all video-recorded events
- MOVEMENT:
- Extremely accurate positioning
- Moving-head operated via either 8- or 16-bit resolution
- High-resolution stepper motors operated via microprocessors to ensure extreme accuracy and smooth movement
- Pan and tilt automatic repositioning
- Moving-head range: 540° (pan), 263° (tilt)
- COLORS:
- Sophisticated color mix system providing CMY color mixing
- Variable CTO color temperature correction
- Fixed color wheel with six complementary colors
- 2 CRI and TM30 optimizer filters
- GOBOS:
- 2 indexable rotating gobo wheels with 7 high-precision glass gobos, plus open position
- Adjustable-speed rotating gobo in both directions
- Gobo diameter: 30.0 mm
- Image diameter: 25.0 mm
- Gobo thickness: 1.1 mm
- FRAMING SYSTEM:
- 4 individually positionable shutter blades on a 100% surface area in all positions
- Rotation of the framing system module: +/- 60°
- IRIS DIAPHRAGM:
- Fast iris diaphragm with adjustable dynamic effects
- Iris range: 15% to 100% open
- FROST:
- 2 frost filters: one light, one heavy
- EFFECTS:
- Focusable black & white graphic animation effect-wheel with continuous rotation in both directions
- Focusable color graphic animation effect-wheel with continuous rotation in both directions
- 2 rotating and indexable prisms: one 5-facet circular, one 4-facet linear
- DIMMER / STROBE:
- Electronic dimmer, allowing perfect light adjustment from 0 to 100% without color variation
- Strobe effect, with speed adjustment from 1 to 25 flashes per second
- SOFTWARE FEATURES:
- Local DMX addressing of luminaire and optional parameters through its built-in LCD control panel
- Remote DMX addressing of luminaire and optional parameters through a standard RDM DMX controller
- Information menu including hour counter, temperature, software version
- HARDWARE FEATURES:
- Graphic LCD display for addressing and special function settings, with flip function
- 5 menu buttons to set the functions
- Excess temperature protection
- Integrated wireless CRMX TiMo™ RDM receiver from LumenRadio™
- Domino-IP65:
- IP65 XLR 5-pin male and female connectors for DMX connection
- IP65 RJ45 IN / OUT connectors for ArtNet™ connection
- IP65 powerCON TRUE1 male connector for power connection
- Domino-IP66:
- DMX IN / OUT tails to bare end for IP66 DMX connection
- Ethernet IN / OUT tails to bare end for IP66 ArtNet™ connection
- Power tail to bare end for IP66 power connection
- CONTROL:
- DMX 512 protocol, through DMX cable or a wireless system
- DMX-RDM compatible
- Stand-alone mode and Master/Slave modes
- ArtNet™ & sACN protocol through Ethernet cable
- Local control panel, with IP65 LCD display
- Choice of 3 DMX modes (from 44 to 66 DMX channels)
- POWER SUPPLY:
- Electronic supply with active PFC
- 120 to 240 Volts – 50/60Hz
- Power: 1,800 W maximum
- COOLING SYSTEM:
- Advanced liquid cooling system
- IP68 self-adjusting variable speed fans for quiet operation (Auto mode)
- Selectable ventilation user modes with a new Silent Mode
- Safety protection against temperatures excesses
- HOUSING:
- Moving-head skeleton made of die-cast aluminium
- Base in die-cast aluminium
- Heatsinks in aluminium and copper
- Moulded covers in in die-cast aluminium
- Two-side handles for transportation
- Four heavy-duty feet for better stability
- IP65 protection rating
- Exterior finish: black (Carbon)
- INSTALLATION:
- Fastening brackets system: two Omega ¼ turn brackets designed for use with standard clamps
- Mounting points: eight ¼ turn locking fittings allowing installation of Omega brackets on luminaire
- Safety cable attachment point
- OPERATING PARAMETERS:
- Operating positions: all (device on floor or fixed to a support)
- Maximum permitted ambient temperature (Ta max): 45° C (113° F)
- Minimum permitted ambient temperature (Ta min): -20° C (-4° F)
- Minimum usage distance: 3.0 m (9.84 ft)
- COMPLIANCE:
- EU (EMC&LVD):
- EMC Directive 2014/30/EU
- LVD Directive 2014/35/EU
- US (Safety & EMC):
- UL 1573
- FCC Part 15, Subpart B: 2018
- EU (EMC&LVD):
- SIZE:
- Product: 490 x 841 x 330 mm (l x h x d)
- Flight-case foam: 715 x 665 x 555 mm (l x h x d)
- WEIGHT:
- Product: 52 kg
