Avlex MI-909R True Digital Bodypack Receiver
Overview
The MI-909R True Digital bodypack receiver, the most compact in the industry, has dual antenna true digital diversity reception providing unsurpassed RF Signal stability and extended range. The bodypack receiver features Stereo, Mono-L, Mono-R and Mixed operational modes with balance control and equalization settings.
Specifications
- RF Frequency Range: UHF 480~604 MHz
- Bandwidth: 64 MHz
- Channel Grid: 25kHz
- Selectable Frequencies: 2561 frequencies in 16 groups per band
- Compatible preset frequencies per group: 16
- Housing: Magnesium and glass-fiber reinforced plastic
- Receiving Mode: True Digital Diversity Receiving
- System Latency: 5.6ms (unencrypted) and 7.84ms (encrypted)
- Oscillation Mode: PLL Synthesized
- Frequency Stability: ± 0.0005% (-10~ +60°C)
- Channel Setup: ACT Sync
- Modulation Type: Digital modulation
- Sensitivity: 10 μ V input level, S/N > 90dB (stereo)
- Spurious Emissions: < 4 nW
- Max S/N ratio: 95dBA
- Frequency Response: 20Hz ~ 15kHz (stereo)
- Stereo Separation: > 95dB
- Volume Control: 126dB (1dB step)
- LCD Display: AF/RF meters, battery status, group & channel, R/L balance
- Output Jack: 3.5mm Ø stereo earphone jack
- Output Power: Left/Right x 120mW @ 16 Ω
- Earphone Impedance: ≥ 16 Ω
- Battery Type: AA X 2
- Current Consumption: Approx 170 mA
- Operating Time: Approx 8 hours (moderate volume)
- T.H.D.: 0.1% @ 1kHz
- Dimensions: 2.6″(W) x .9″(H) x 3.2″ (L)〞
- Weight: 98g / 3.5 oz
- Operating Temperature: -10 ~ +60°C
