Avlex ACT-818 Digital Wideband Encryption-Capable Single Channel Receiver
FEATURES:
SPECIFICATIONS:
- Frequency Range: Bands 5UA & 5NU, UHF 480–590MHz
- Bandwidth: Bands 5UA and 5NU: 2,161 selectable frequencies / 192 preset channels with 16 user identifable preset
- 16+ simultaneous channel operation
- Receiver Mode: Digital diversity
- Audio Sampling: 24-bit / 44.1 kHz rate
- Audio Compression: 2nd generation DSP inertial coding
- Latency: <2.7ms
- Frequency Response: 20Hz~20kHz (-2dB)
- Audio Dynamic Range: >115dB(a)
- T.H.D. >0.03% @ 1kHz
- Encryption: 256-bit
- Housing: Metal
- Sensitivity: 15dBμV at S/N=118dBA
- Digital Equalizer: 10 preset microphone capsule modeling
- Digital Audio Interface: AES/EBU output
- PC Interface: USB or RS-232. Proprietary MIPRO ACT-BUS
- Power Supply: built-in 100~240V AC switching power supply
- Dimensions (W x H x D): 210 × 44 × 230mm / 8.3 × 1.7 × 9″
- Weight: Approx. 1.1 kg / 2.4 lbs
