Product Description
Audix OM5 Professional Dynamic Vocal Microphone
The OM5 vocal dynamic microphone is made with an extremely tight and uniformly controlled hypercardioid polar pattern which isolates the vocals from the rest of the instruments on stage or in a studio.
Used on stage, in studios and for broadcast applications, the OM5 hypercardioid microphone has a reputation for clarity, resistance to feedback, and the ability to handle SPLs in excess of 144 dB without distortion.
The OM5 dynamic vocal microphone is naturally attenuated at 120 Hz to reduce boominess and handling noise. The mid-range is tailored to provide an extra presence in the vocals allowing the vocalist to be easily heard through the main speakers as well as the monitors.
Designed, assembled, and tested by Audix in the USA.
FEATURES
- Concert level, professional vocal mic for live sound, broadcast, and studio
- Very tight pattern control, exceptional clarity for premium PA systems
- Clear, accurate sound with slight mid-range boost
- Allows vocals to cut through the stage mix
- Extreme off-axis rejection provides excellent isolation on stage
- VLM Capsule
- Designed, assembled & tested in the USA
- 5 year warranty
APPLICATIONS
- Lead or backing vocals
- Live recording
- Broadcast
- Home studio - vocal and instrument
- Sax, brass, guitar, dobro, flute, percussion, drums
OPTIONAL ACCESSORIES
- WS357 - Optional high quality external foam windscreen for reducing wind, sibilance, and pop noise.
- CBL20 - 20’ premium XLR-XLR balanced mic cable. Quad conductor, twisted pair with braided shield for maximum conductivity. 6mm PVC jacketed.
- CBLDR25 - 25’ premium right angle XLR-XLR balanced mic cable. Quad conductor, twisted pair with braided shield for maximum conductivity. 6mm PVC jacketed.
- T50K - Professional impedance matching transformer that allows a low impedance mic to be connected to a high impedance input.
- TRIPOD - Metal tripod desktop stand for use with any 5/8” threaded mic clip
WHAT'S IN THE BOX?
- 1x OM5 Vocal Microphone
- 1x MC1 Microphone Clip
- 1x P1 Carrying pouch
SPECIFICATIONS
| Transducer Type | Dynamic |
|---|---|
| Frequency Response | 48 Hz – 19 kHz |
| Polar Pattern | Hypercardioid |
| Output Impedance | 200 ohms |
| Sensitivity | 2 mV / Pa @ 1k |
| Capsule Technology | VLM Type C |
| Off-Axis Rejection | >30 dB |
| Maximum SPL | ≥144 dB |
| Power Requirements | None |
| Connector | 3-pin XLRm |
| Polarity | Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector |
| Materials / Finish | Zinc Alloy / Black Finish |
| Weight | 330 g / 11.6 oz |
| Length | 176 mm / 6.9 in |
