Product Description
Audix D6 Professional Dynamic Instrument Microphone
The D6 dynamic instrument microphone is used for stage, studio, and broadcast applications. Designed with a cardioid pickup pattern for isolation and feedback control, the D6 drum microphone is equipped with a VLM™ diaphragm for natural, accurate sound reproduction.
Lightweight, compact, and easy to position, the D6 cardioid microphone is an excellent choice for miking instruments requiring extended low-frequency reproduction such as kick drums, large toms, and bass cabinets. The D6’s transformerless design, low impedance, and balanced output allow for interference-free performance.
Designed, machined, assembled, and tested by Audix in the USA.
WHAT'S IN THE BOX?
- 1x D6 Instrument Microphone
- 1x DCLIP Microphone Clip
- 1x P1 Carrying Pouch
FEATURES
- Professional dynamic instrument microphone for live sound or studio
- Ground-shaking low end with excellent definition and clarity
- VLM Capsule
- Designed, machined, assembled & tested in the USA
- 5 year warranty
APPLICATIONS
- Live stage, recording
- Kick drum
- Floor tom
- Bass cabinets
- Leslie bottom
MODEL VARIATIONS
- D6S - Same as D6 with a silver anodized finish
- D6KD - Same as D6 with boomstand
SPECIFICATIONS
Transducer Type | Dynamic |
---|---|
Frequency Response | 30 Hz – 15 kHz |
Polar Pattern | Cardioid |
Output Impedance | 280 ohms |
Sensitivity | 0.8 mV / Pa @ 80 Hz |
Capsule Technology | VLM Type E |
Off-Axis Rejection | >20 dB |
Maximum SPL | ≥144 dB |
Power Requirements | None |
Connector | 3-pin XLRm |
Polarity | Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector |
Materials / Finish | Machined Aluminum / Black Finish |
Weight | 254 g / 8.9oz |
Length | 117 mm / 4.6 in |
Other Details
This microphone is under warranty for a period of 5 years to be free of defects in material and workmanship. In the event of a product failure due to materials or workmanship, Audix will repair or replace said product at no charge with proof of purchase. Audix does not pay or reimburse shipping costs for warranty repairs or returns. The warranty excludes any causes other than manufacturing defects, such as normal wear, abuse, environmental damage, shipping damage or failure to use or maintain the product per the supplied instructions. No Implied Warranties: All implied warranties, including but not limited to implied warranties of merchantability and fitness for a particular purpose are hereby excluded. The liability of Audix, if any, for damages relating to allegedly defective products shall be limited to the actual price paid by Dealer for such products and shall in no event include incidental or consequential damages of any kind. Should your microphone fail in any way, please contact the Audix Service department at 503.682.6933. A Return Authorization is required before returning any product. OTHER THAN THIS WARRANTY, AUDIX MAKES NO WARRANTIES, EXPRESS OR IMPLIED, WITH RESPECT TO THE PRODUCTS, THE USE OF THE PRODUCTS, THE PERFORMANCE OF THE PRODUCTS. AUDIX SHALL NOT BE LIABLE FOR SPECIAL INCIDENTAL, CONSEQUENTIAL, INDIRECT OR SIMILAR DAMAGES ARISING FROM OR BASED ON THE SALE, USE, STORAGE OR DISPOSAL OF THE PRODUCTS, AUDIX’S SERVICE WORK, BREACH OF WARRANTY, BREACH OF CONTRACT. NEGLIGENCE, OR ANY OTHER THEORY OF LIABILITY, EVEN IF AUDIX HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.Product Videos
