Product Description
Audix ADX60 Boundary Condenser Microphone
A professional pre-polarized condenser microphone, the ADX60 is designed for stage, studio, and broadcast applications. The ADX60 is highly sensitive and able to handle distance and area miking for various applications including conferences, plays, theatre, and acoustic instruments.
The ADX60 has a uniformly controlled hemicardioid polar pattern and is designed to capture a designated area. This microphone requires a 9 – 52 V phantom power for operation and is equipped with a 25′ cable and phantom power adapter.
The ADX60 boundary condenser microphone is easy to position, durable, and is manufactured with a high-performance 12 mm capsule, steel mesh grille, and space-saving mini-XLR connector.
WHAT'S IN THE BOX?
- 1x ADX60 Condenser Microphone
- 1x CBL60 25′ Detachable Microphone Cable With Mini XLRf Connectors
- 1x APS910 Phantom Power Adapter
- 1x P1 Carrying Pouch
SPECIFICATIONS
Transducer Type |
Pre-Polarized Condenser |
Frequency Response |
50 Hz – 18 kHz |
Polar Pattern |
Cardioid |
Output Impedance |
250 ohms balanced |
Sensitivity |
9 mV / Pa @ 1k |
Equivalent Noise Level |
<29 dB (A-weighted) |
Signal to Noise Ratio |
>65 dB |
Maximum SPL |
≥130 dB |
Power Requirements |
None |
Connector |
Miniature female XLR connector |
Polarity |
Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 |
Materials / Finish |
Die Cast Zinc / Black Finish |
Weight |
143 g / 5 oz |
Length |
80 mm / 3.1 in |
Other Details
Unless otherwise noted in the products listed below, all Audix products purchased in the USA feature a one-year limited warranty.
All Audix products are warranted to the original purchaser to be free of defects in materials and workmanship from date of purchase as follows:
5 years for VLM Dynamic microphones
3 years for Fusion Series and Condenser microphones
1 year for all other products
If a product fails within the warranty period due to materials or workmanship, Audix will repair or replace said product at Audix discretion, at no charge with proof of purchase from an authorized Audix dealer. Audix does not pay or reimburse shipping costs for warranty repairs or returns. The warranty excludes any causes other than manufacturing defects, such as normal wear, abuse, environmental damage, shipping damage, or failure to use or maintain the product per the supplied instructions.
No Implied Warranties: All implied warranties, including but not limited to implied warranties of merchantability and fitness for a particular purpose are hereby excluded. The liability of Audix, if any, for damages relating to allegedly defective products shall be limited to the actual price paid by Dealer for such products and shall in no event include incidental or consequential damages of any kind.
OTHER THAN THIS WARRANTY, AUDIX MAKES NO WARRANTIES, EXPRESS OR IMPLIED, WITH RESPECT TO THE PRODUCTS, THE USE OF THE PRODUCTS, THE PERFORMANCE OF THE PRODUCTS.
AUDIX SHALL NOT BE LIABLE FOR SPECIAL, INCIDENTAL, CONSEQUENTIAL, INDIRECT OR SIMILAR DAMAGES ARISING FROM OR BASED ON THESALE, USE, STORAGE OR DISPOSAL OF THE PRODUCTS, AUDIX’S SERVICE WORK, BREACH OF WARRANTY, BREACH OF CONTRACT, NEGLIGENCE, OR ANY OTHER THEORY OF LIABILITY, EVEN IF AUDIX HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
GOVERNING LAW: This agreement will be governed by and construed in accordance with the laws of the state of Oregon. Venue for any action or proceeding shall exclusively be in Multnomah County, Oregon, U.S.A.
