Product Description
Audix ADX40 Miniature Hanging Microphone
The ADX40 is a miniaturized condenser microphone designed to hang from an overhead position for applications such as group vocals, choir, theatrical production, and room ambiance.
Having a uniformly controlled cardioid polar pattern, the ADX40 helps isolate the area or section being miked from other vocals or instruments on stage. The ADX40 is also available in a hypercardioid polar pattern for tighter pick-up control. With a wide frequency range of 40 Hz – 20 kHz, the ADX40 provides natural sound with an exceptional sound response.
The ADX40 miniature hanging condenser microphone is supplied with an attached 30′ shielded cable, external windscreen, wire hanger for positioning, and phantom power adapter. 9 -52 V phantom required.
FEATURES
- Small, lightweight, low profile
- Excellent for distance miking
- Available in 2 polar patterns
- Available in black or white
APPLICATIONS
- Overhead mic for choir, group vocal
- Orchestra miking
- Ambient room miking
- Symphonic area miking
- School plays, theatrical productions
REPLACEMENT CAPSULES
- CPSADXC - Cardioid in black
- CPSADXCW - Cardioid in white
- CPSADXHC - Hypercardioid in black
- CPSADXHCW - Hypercardioid in white
- MODEL VARIATIONS
- ADX40W - Same as above in white
- ADX40HC - Hypercardioid capsule in black
- ADX40WHC - Hypercardioid capsule in white
SUPPLIED ACCESSORIES
- APS910 - Cylindrical preamplifier for use with phantom power
- HANGER40 - Wire hanger
- P1 - Carrying pouch - 30’ attached shielded cable with mini XLR-f connector
- WS20 - External foam windscreen (black) or WS20W (white)
OPTIONAL ACCESSORIES
- APS911 - Battery/phantom preamplifier with on/off switch and roll-off
- MCHANGER - Clear plastic clip
- MCMICRO - Microphone stand adapter
- MCSWIVEL- Shockmount adapter with ball and socket pivot
- SMTMICRO - Microphone stand adapter with shockmount ring
SPECIFICATIONS
Transducer Type | Condenser |
Frequency Response | 40 Hz – 20 kHz |
Polar Pattern | Cardioid Hypercardioid (ADX40HC) |
Output Impedance | 250 ohms balanced |
Sensitivity | 5 mV / Pa @ 1k |
Equivalent Noise Level | 29 dB (A weighted) |
Signal to Noise Ratio | 65 dB |
Maximum SPL | ≥130 dB |
Power Requirements | 9 – 52 Volts phantom |
Cable/Connector | Shielded 30’ terminating to a miniature 3 pin Female XLR connector |
Polarity | Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 |
Materials / Finish | Brass / Black E-Coat |
Weight | 110 g / 4 oz |
Length | 30 mm / 1.2 in |
