Audix ADX10P Lavalier Microphone Cardioid With 8' Cable
WIRELESS COMPONENT CONDENSER VOCAL MICROPHONE
The ADX10 is a miniaturized condenser microphone designed for lavalier applications such as speech, presentation, and theatrical production. The ADX10 has the ability to accurately capture and reproduce vocals from a comfortable distance of 4″- 8″. This mic is clear, resistant to feedback, and easy to use.
Designed with a uniformly controlled cardioid polar pattern, the ADX10 helps to isolate the area or section being miked from other vocals or instruments on stage. The ADX10 has a smooth, accurate frequency range of 50 Hz – 18 kHz. This mic is lightweight, low profile, and has a natural sound with an exceptional sound response.
Primarily for use with Audix wireless systems, the ADX10 cardioid condenser microphone includes a tie-clip and a 3′ attached cable terminating to a mini-XLRf connector.
ADX10P - For hard wired application. Includes an 8' cable terminating to a mini-XLRf connector tie clip, external windscreen and a phantom power adapter module. 9 - 48 V phantom power required.
WHAT'S IN THE BOX?
1x ADX10 Vocal Microphone
1x MC10L tie clip
1x WS10 external foam windscreen
1x P1 carrying pouch
Transducer Type | Pre-polarized Condenser |
---|---|
Frequency Response | 50Hz – 18kHz |
Polar Pattern | Cardioid |
Output Impedance | 250 Ohms |
Sensitivity | 5 mV/Pa @1k |
Equivalent Noise Level | <29 dB (A-weighted) |
Signal to Noise Ratio | >65 dB |
Maximum SPL | ≥120 dB |
Power Requirements | 9-52 V phantom |
Connector | Shielded 3’ terminating to a miniature 3 pin Female XLR connector |
Polarity | Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 |
Materials / Finish | Machined Brass / Black Finish |
Weight | 21 g / 0.74 oz |
Length | 25 mm / .98 in |
