Product Description
Audix ADX10 Wireless Condenser Vocal Microphone
The ADX10 is a miniaturized condenser microphone designed for lavalier applications such as speech, presentation, and theatrical production. The ADX10 has the ability to accurately capture and reproduce vocals from a comfortable distance of 4″- 8″. This mic is clear, resistant to feedback, and easy to use.
Designed with a uniformly controlled cardioid polar pattern, the ADX10 helps to isolate the area or section being miked from other vocals or instruments on stage. The ADX10 has a smooth, accurate frequency range of 50 Hz – 18 kHz. This mic is lightweight, low profile, and has a natural sound with an exceptional sound response.
Primarily for use with Audix wireless systems, the ADX10 cardioid condenser microphone includes a tie-clip and a 3′ attached cable terminating to a mini-XLRf connector.
The ADX10 is characterized with a uniformly controlled cardioid polar pattern, helping to isolate the area or section being miked from other vocals or instruments on stage. With a smooth and accurate frequency range of 50 Hz - 18 kHz, the ADX10 is lightweight and will provide natural sound with exceptional transient response. The ADX10, primarily for use with Audix wireless systems, includes a tie-clip, and a 3’ attached cable terminating to a mini-XLRf connector. The ADX10 may also be used as a wired mic. Simply order the APS910 or APS911 phantom power adapter for use with a standard mic cable
SUPPLIED ACCESSORIES
- MC10L - Metal clip with tension fit wire loop
- P1 - Carrying pouch
- WS10 - External foam windscreen
OPTIONAL ACCESSORIES
- APS910 - Phantom power adapter
- APS911 - Battery / Phantom power adapter with on off switch and bass roll-off
- WS10S - Snap to fit external windscreen
FEATURES
- Small, lightweight, low profile
- Natural, accurate sound reproduction
- Easy to use and set up
- Field replaceable capsule
- Available for wireless and wired applications
APPLICATIONS
- Speech
- Flute
- Acoustic instruments and hand drums
SPECIFICATIONS
Transducer Type | Pre-polarized Condenser |
Frequency Response | 50Hz – 18kHz |
Polar Pattern | Cardioid |
Output Impedance | 250 Ohms |
Sensitivity | 5 mV/Pa @1k |
Equivalent Noise Level | <29 dB (A-weighted) |
Signal to Noise Ratio | >65 dB |
Maximum SPL | ≥120 dB |
Power Requirements | 9-52 V phantom |
Connector | Shielded 3’ terminating to a miniature 3 pin Female XLR connector |
Polarity | Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 |
Materials / Finish | Machined Brass / Black Finish |
Weight | 21 g / 0.74 oz |
Length | 25 mm / .98 in |
