Product Description
Audio-Technica ATW-DA410 UHF Antenna Distribution System
Overview
The ATW-DA410 is a UHF (wide-band 470-990 MHz) active unity-gain diversity antenna distribution system that enables one pair of passive or active antennas to feed multiple wireless systems. The unit is equipped with two 1:4 active splitters, allowing each antenna (channels A and B) to connect to as many as four wireless receivers. A switch on the unit’s rear panel provides the option of supplying +12V DC to the antenna input jacks.
The ATW-DA410 also includes a built-in 1:2 passive splitter/2:1 passive combiner for both channel A and channel B, giving users a convenient way to increase the number of outputs from a single antenna or to harness two antennas for input into a single channel.
The ATW-DA410 is designed to maintain the high density performance of Audio-Technica’s 6000 Series wireless system, utilizing low-noise and low-distortion components that provide a high level of immunity to intermodulation distortion (IMD), for the use of 31 simultaneous channels within 4 MHz of bandwidth.
Features
- Provides antenna distribution for wireless systems operating in the 470-990 MHz range
- Equipped with two “1-in, 4-out” channel splitters
- A switch supplies +12V DC to antenna input jacks (for use with powered antennas)
- Includes built-in 1:2 passive splitter/2:1 passive combiner for each channel
- Maintains optimal IMD performance in high channel count applications
