Product Description
Audio-Technica ATW-2129CI 2000 Series Wireless Lavalier Microphone System
Overview
The Audio-Technica 2000 Series stands as a 10-channel frequency-agile UHF wireless system meticulously crafted to cater to diverse applications encompassing MI/live performance, fixed installation, public address, A/V rental houses, and places of worship. It embodies the attributes of a top-tier professional wireless system while maintaining an exceptionally cost-effective price point. Notably, it incorporates switchable antenna power for enhanced versatility. Furthermore, the optional ATW-CHG2 two-bay recharging station complements this system, providing the requisite power for recharging NiMH batteries housed within two ATW-T220 handheld transmitters and/or ATW-T210 body-pack transmitters in any desired combination.
Features
- Frequency-Agile UHF System: Provides a 10-channel frequency-agile system operating in UHF for versatile and interference-free performance.
- Versatile Applications: Suited for various applications including MI/live performance, fixed installations, public address, A/V rental houses, and places of worship.
- Professional-Quality Performance: Delivers high-quality, professional-grade wireless performance at an affordable price point.
- Switchable Antenna Power: Offers switchable antenna power for enhanced functionality and adaptability.
- ATW-CHG2 Recharging Station: Optional two-bay recharging station facilitates the recharging of NiMH batteries in two ATW-T220 handheld transmitters and/or ATW-T210 body-pack transmitters, providing convenient power management.
In The Box
- ATW-R2100c receiver1
- ATW-T210c body-pack transmitter1
- AT829cW lavalier microphone1
- Flexible UHF antennas2
- AC adapter (country dependent)1
- Rack-mount adapters1
- AT8456a Quiet-Flex™ stand clamp
Specifications
System
- Operating Frequencies Band I: 487.125 to 506.500 MHz
- Modulation Mode FM
- Maximum Deviation ±40 kHz
- Frequency Response 100 Hz to 15 kHz (+1 dB, -3 dB)
- Operating Range 100 m (300'), typical (Open range environment with no interfering signals.)
- Total Harmonic Distortion < 1% (at 1 kHz, ±20 kHz deviation)
- Operating Temperature Range
- 5ºC to 45ºC (41ºF to 113ºF)
- Battery and LCD performance may be reduced at very low temperatures.
- Number Of Channels: 10 total
- Notes
- Fourth-generation 2000 Series (“c” version) components:
- ATW-R2100c receiver
- ATW-T210c body-pack transmitter
- ATW-T220c cardioid dynamic microphone/transmitter
- Third-generation 2000 Series (“b” version) components:
- ATW-R2100b receiver
- ATW-T210b body-pack transmitter
- ATW-T220b cardioid dynamic microphone/transmitter
- Second-generation 2000 Series (“a” version) components:
- ATW-R2100a receiver
- ATW-T210a body-pack transmitter
- ATW-T220a cardioid dynamic microphone/transmitter
- First-generation 2000 Series (original) components:
- ATW-R2100 receiver
- ATW-T210 body-pack transmitter
- ATW-T220 cardioid dynamic microphone/transmitter
Handheld Transmitter
- RF Power Output
- High: 30 mW
- Low: 10 mW (switchable), at 50 ohms
- Spurious Emissions: Following federal and national regulations
- Microphone Element: Dynamic cardioid
- Battery Type
- Two 1.5V AA alkaline (not included) or two 1.2V AA NiMH (not included)
- Recharging power for NiMH batteries (with ATW-CHG2)
- U.S./Canada/Latin America: 3.2 V DC, 230 mA x2
- Other world areas: 3.2 V DC, 320 mA x2
- Battery Life
- High: 7 hours (alkaline)
- Low: 9 hours (alkaline)
- Depending on battery type and use pattern
- Dimensions: 232 mm (9.13") long, 48 mm (1.89") diameter
- Net Weight: 252 g (8.9 oz), without batteries
Bodypack
- RF Power Output: High: 30 mW, Low: 10 mW (switchable), at 50 ohms
- Battery Life
- High: 7 hours (alkaline)
- Low: 9 hours (alkaline)
- Depending on battery type and use pattern
- Battery Type
- Two 1.5V AA alkaline (not included) or two 1.2V AA NiMH (not included)
- Recharging power for NiMH batteries (with ATW-CHG2)U.S./Canada/Latin America: 3.2 V DC, 230 mA x2Other world areas: 3.2 V DC, 320 mA x2
- Dimensions: 66 mm (2.6") W x 22.5 mm (0.89") D x 92.3 mm (3.63") H
- Input Connections
- Four-pin Locking Connector
- Pin 1: GND
- Pin 2: INST INPUT
- Pin 3: MIC INPUT
- Pin 4: DC BIAS +9V
- Net Weight: 81 g (2.9 oz), without batteries
- Spurious Emissions: Following federal and national regulations
Receiver
- Receiving System: True diversity
- Image Rejection: 60 dB nominal, 55 dB minimum
- RF Sensitivity: 20 dBuV at 60 dB S/N ratio (50 ohms termination)
- Maximum Output Level: XLR, balanced: +9 dBV, ¼" (6.3 mm), unbalanced: +4 dBV
- Antenna Input
- BNC-type, 50 ohms
- Bias voltage 12V DC, 60 mA, each
- Power Requirements: 12-18V DC, 500 mA
- Dimensions: 210 mm (8.27") W x 162.2 mm (6.39") D x 44 mm (1.73") H,br>Not including BNC connectors or feet.
- Weight: 1 kg (35.3 oz), without accessories
- Audio Output Attenuator (ATTN): Balanced Audio Output Attenuator: Two position switch: 0 / -12 dB
