Product Description
Audio-Technica ATW-2110bI
ATW-2110b - ATW-R2100b receiver and ATW-T210a UniPak® transmitter.
Frequency Band: I
Select a wireless essentials microphone or cable to complete the system.
- Audio-Technica’s 2000 Series is a 10-channel frequency-agile UHF wireless system designed to suit a variety of applications, including MI/live performance, fixed installation, public address, A/V rental houses and places of worship. It offers all the advantages of a high-quality, professional wireless system at an extremely affordable price. Features switchable antenna power. Also, the optional ATW-CHG2 two-bay recharging station provides power to recharge NiMH batteries in two ATW-T220a handheld transmitters and/or ATW-T210a UniPak® transmitters in any combination.
Offering 10 selectable channels and True Diversity UHF wireless technology, the 2000 Series features automatic frequency scanning. At the touch of a button, this function automatically determines and sets the best available frequency. Any of the 2000 Series’ 10 channels may be used together without any frequency coordination problems or group selection issues. The 2000 Series also incorporates Audio-Technica’s Tone Lock™ squelch plus an easy-to-read LCD information display.
Features:
- Serious advances in affordable professional wireless
- Clear sound quality and rock-solid, dependable performance
- Automatic frequency scanning
- 10 compatible user-switchable channels
- Antenna power available for powered antennas & other in-line RF devices
- True Diversity operation selects the better signal from the two receiver sections, reducing dropouts
- Tone Lock™ tone squelch system fights interference
- Rugged metal half-rack receiver with soft-touch controls and LCD display
- Balanced XLR and unbalanced 1/4” output jacks enable use with a wide variety of audio gear
- Switchable transmitter power output with high and low settings offered
- Includes rack-mount kit and detachable UHF antennas
- Ground-lift switch helps eliminate audible hum caused by ground loops between the sound system and receiver
- ATW-T220a Handheld Microphone/Transmitter features PRO 41 Capsule for maximum feedback rejection and consistent sound
- ATW-CHG2 charger available for ATW-T220a & ATW-T210a transmitters
-
RECEIVER SPECIFICATIONS Receiving System True diversity Image Rejection 60 dB nominal, 55 dB minimum RF Sensitivity 20 dBuV at 60 dB S/N ratio
(50 ohms termination)Antenna Input BNC-type, 50 ohms
Bias voltage 12V DC, 60 mA, eachPower Requirements 12-18V DC, 500 mA Dimensions 210.0 mm (8.27") W x
162.2 mm (6.39") D x
44.0 mm (1.73") H
Not including BNC connectors or feet.Net Weight 1.0 kg (35.3 oz), without accessories Accessories Included Two flexible UHF antennas; AC adapter (country dependent); rack-mount adapters
ADDITIONAL RECEIVER SPECS
Maximum Output Level:
XLR, balanced: +9 dBV
¼" (6.3 mm), unbalanced: +4 dBV
Balanced Audio Output Attenuator:
Two position switch: 0 / -12 dB
BODY-PACK TRANSMITTER SPECIFICATIONS | |
---|---|
RF Power Output | High: 30 mW, Low: 10 mW (switchable), at 50 ohms |
Spurious Emissions | Following federal and national regulations |
Input Connections | Four-pin Locking Connector Pin 1: GND Pin 2: INST INPUT Pin 3: MIC INPUT Pin 4: DC BIAS +9V |
Batteries | Two 1.5V AA alkaline (not included) or two 1.2V AA NiMH (not included) Recharging power for NiMH batteries (with ATW-CHG2) U.S./Canada/Latin America: 3.2 V DC, 230 mA x2 Other world areas: 3.2 V DC, 320 mA x2 |
Battery Life | High: 7 hours (alkaline) Low: 9 hours (alkaline) Depending on battery type and use pattern. |
Dimensions | 66.0 mm (2.60") W x 22.5 mm (0.89") D x 92.3 mm (3.63") H |
Net Weight | 81 g (2.9 oz), without batteries |
