Product Description
Audio-Technica AT-ART9XI Magnetic-Core Dual-Moving-Coil Cartridge
Key Features
- Magnetic-Core Moving-Coil Cartridge
- Flagship Model, Replaces the AT-ART9
- Specially Designed Magnetic Circuit
- Strong Output Voltage
- Increased Magnetic Energy
- Dual Moving Coils in Inverted V Shape
- Special Line Contact Stylus
- Solid Boron Cantilever
- PCOCC Coils for Precise Transmission
- Excellent Stability and Low Resonance
Overview
Replacing the AT-ART9 as the company's flagship magnetic core dual moving coil cartridge, the Audio-Technica Consumer AT-ART9XI is designed to deliver premium turntable playback for vinyl enthusiasts, providing nuanced character, distortion-free sound quality, distinct separation, and clear localization.
The specially designed magnetic circuit allows the AT-ART9XI to achieve a strong output voltage of 0.5mV, which enables wide dynamic response. Extended frequency response and heightened separation are made possible by dual moving coils—configured in an inverted V shape—as well as the special line contact stylus and solid boron cantilever. The AT-ART9XI includes a complete hardware kit for easy installation to a headshell or integrated tonearm.
Magnetic Core
Inverted V-Shape
Special Line Contact Stylus
Increased Magnetic Energy
Redesigned Coil Armature
PCOCC Coils
Stable Playback
Low Resonance
Easy Installation
Specs
| Type | Magnetic Core Dual Moving Coil |
| Mounting | 0.5" / 12.7 mm |
| Frequency Response | 20 Hz to 50 kHz |
| Construction Material | Aluminum and Plastic |
| Channel Separation | 30 dB at 1 kHz |
| Channel Balance | 0.5 dB at 1 kHz |
| Output Voltage | 0.5 mV (1 kHz and 5 cm/sec) |
| Vertical Tracking Angle | 20° |
| Tracking Force | Vertical Tracking Force Range: 1.6 to 2 g (1.8 g Standard) |
| Stylus | Stylus Shape: Special Line Contact Stylus Construction: Nude |
| Stylus Cantilever | 0.01" / 0.28 mm Diameter, Solid Boron |
| Coil | Coil Impedance: 12 Ohms at 1 kHz Coil Inductance: 25 µH at 1 kHz |
| DC Resistance | 12 Ohms |
| Static Compliance | 25 × 10-6 cm/Dyne |
| Dynamic Compliance | 15 × 10-6 cm/Dyne (100 Hz) |
| Recommended Load Impedance | Minimum 100 Ohms |
| Threaded Holes | 2 x M2.6 |
