Product Description
Atlas Sound TT-FK4-2 Texas Tough Fan Kit for 25" Deep Racks
Overview
The TT-FK4-2 fan kit provides quiet and effective dissipation of heat, for equipment mounted in Texas Tough 25” deep cabinets. The included filter cover plates allow for cooling path control.
Two 115 CFM 4” (100mm) diameter fans provide 230 total CFM to ensure maximum air flow. Fan motors utilize ball bearing supports for the best performance and long life. On the outside, users are protected from rotating blades by the wire mesh screen. On the inside, users are protected by the chrome plated finger guard. Unit also comes with a 6’ polarized 115VAC power cord and eight 16-guage CRS black powder-coated filter covers.
Fans may be mounted for exhaust or intake cooling.
Features
-
Designed for Texas Tough 25” deep racks
-
Mounts in existing Texas Tough rack top panel
-
Dual fans with 115 CFM rating (each) provide rapid and efficient heat dissipation
-
Suitable for exhaust cooling or intake circulation
-
Includes Texas Tough filter cover plates to help control cooling path
-
Finger guards and power cord included
Specifications
CFM | 115 CFM per fan (230 CFM combined) |
Voltage | 115 VAC |
Power Consumption | 15W per fan (30W combined) |
Length | 4.72" (120mm) per fan |
Width | 4.72" (120mm) per fan |
Height | 1.51" (38.4mm) per fan |
Power Cord | 6 ft |
Warranty Period | 12 months from date of purchase |
