Product Description
Atlas Sound TSD-PA122G 12W x 2 @ 4Ω 2-Channel Power Amplifier
The TSD-PA122G 4Ω stereo amplifier is perfectly suited for almost any general amplification requirement. Perfect for adding sound reinforcement to small projector systems as it provides ample power to drive up to four 8Ω speakers in a classroom or boardroom application. Output is 12W per channel at 4Ω or 24W bridged mono at 8Ω. Input is via balanced stereo phoenix style and unbalanced RCA connectors. Front panel gain controls provide adjustment for both left/right or bridged outputs and include removable knobs.
Unit requires Power Supply that is sold separately for proper function, multiple TSDs can be powered with one power supply based on current requirements. This unit has a power requirement of 500mA at 8Ω and 1000mA at 8Ω so you must use either the TSD-PS24V500MA or TSD24V2500MA power supply.
Features
- 12W x 2 @ 4Ω
- 24W Bridged @ 8Ω
- Two RCA Balanced Inputs
- Removable Level Controls
- Input Peak Indicator LEDs
- Input Signal Indicator LEDs
- Removable Phoenix Style I/O Connectors
- Separate Ground Connections
- Power Supply Sold Separately
Specs
FREQUENCY RESPONSE | 20Hz - 20kHz |
POWER RATING | 12W @ 4Ω x 2 CH, 6W @ 8Ω x 2 CH, 24W @ 8Ω Bridged |
BALANCED INPUT IMPEDANCE | 10kΩ Balanced, 5kΩ Unbalanced |
LINE INPUT LEVEL | 500mV (-6dBV) Balanced |
HEIGHT | 1.5" (3.81 cm) |
WIDTH | 4" (10.16 cm) |
DEPTH | 2.5" (6.35 cm) |
WEIGHT | 6oz., .165kg |
VOLTAGE COMPATIBILITY | 24V |
