Product Description
Atlas Sound PM8SUB 8-inch Pendant Mount Subwoofer
The AtlasIED PM8SUB-B/PM8SUB-WH matches the sonic quality of the high performance 8” Strategy II Series FAP8SUB driver. This speaker is the same device used in AtlasIED’s successful model FAP8SUB in-ceiling subwoofer package. Mounted down-firing in an attractive enclosure, the PM8SUB provides natural sounding, wide coverage for low height installations while delivering excellent low frequency response for both music applications.
Attaching a PM8SUB to most over head surfaces is a breeze. For open beam ceilings a 3 meter cable kit is included with a self gripping ferrule system. If down pipe installation from hard ceiling material is required, any 3/4" ceiling fan installation kit may be utilized. These kits are readily available under the FANTECTM brand from home improvement stores with various down pipe length options to provide installation ease regardless of ceiling angle (Up to 45°).
Available in Black or White.
- Integrated 70.7V Transformer with Power Taps at 7.5, 15, 30, & 60 Watts with 8Ω Bypass
- 3 Meters of 2mm Cable & Mounting Hardware Included
- Compatible with Standard 3/4" Ceiling Fan Hardware
- Ideal Low Frequency Driver for High Ceiling Applications
FREQUENCY RESPONSE | 46Hz - 160Hz |
SENSITIVITY | 92dB Average |
SPEAKER TYPE | Subwoofer |
IMPEDANCE | 7.5, 15, 30, 60W & 8Ω |
8Ω RMS POWER | 150 Watts |
DISPERSION | Omni |
CROSSOVER | Three Pole Design 18dB / octave @ 120Hz |
ENCLOSURE VOLUME | 1075 cu in |
HEIGHT | 16 5/8" (42.2148 cm) |
DIAMETER | 12 1/4" (31.115 cm) |
SHIPPING WEIGHT | 21.00 lbs (9.53 kgs) |
