Product Description
Atlas Sound IPS-ZC4 IP-To-Analog 4-Zone POE Gateway
AtlasIED IPS-ZC4 SIP-to-Analog 4-endpoint zone gateways are perfect for extending communication off network to create analog overhead paging systems for those environments where the SIP servers or VoIP communications managers may not support paging or where 3rd party notification applications are not required.
AtlasIED IPS-ZC4 SIP–to–Analog gateways can register as SIP devices directly to a SIP server or VoIP communications manager and can provide up to 15 paging groups using its 4-zone outputs. When a caller dials a paging number, the IPS-ZC4 provides a one-way voice path to its analog outputs that have been designated to receive paging.
When used within a Cisco Environment, this same SIP–to–Analog 4 endpoint zone gateway from AtlasIED can join Cisco’s Unified Survivable Remote Site Telephony (SRST) as supported devices within SRST endpoint architecture. Cisco’s SRST provides remote location call- processing redundancy when access to the centralized Cisco Unified Communications Manager is interrupted because of a WAN outage. The ability to extend LAN communication between any combination of phones and speakers with visual notifications is particularly critical during an emergency,which may be the actual cause of the WAN outage.
Ideal for Corporate Applications, Education Institutions, Entertainment Complexes, Industrial Facilities, Government Buildings, Healthcare Facilities, Houses of Worship, Transportation Hubs; anywhere the need for critical alerts/public address exists and a single enterprise-class communications platform is preferred.
Features
- Four Paging Zones
- Fifteen Paging Zone Groups
- PoE 802.3af Enabled
- SIP RFC 3261 Compatible
- Compatible with IP/PBX Servers
- Delayed Paging
- Web-Based Configuration
Specs
- Ethernet I/F: 10/100 Mbps
- Protocol: SIP RFC 3261 Compatible
- Power Input: PoE 802.3af or 48VDC
- Operating Temperature Range: -30° to 55° C (-22° to 131° F)
- Payload Types: G711
- Regulatory Compliance: FCC Class A, UL 60950
- Output Signal Amplitudes: 2.0 VPP Maximum
- Total Harmonic Distortion: 0.5% Maximum
- Width: 6.2" (154.48mm)
- Height: 1.22" (30.99mm)
- Depth: 4.5" (114.3mm)
- Weight: 1.6 lbs. (0.73kg)
