Product Description
Atlas Sound IP-SDMFLED PoE+ Indoor Wall Mount IP Speaker with LED Display, LED Flashers, and Talkback Microphone
Overview
AtlasIED IPX Series IP-SDMFLED indoor wall mount IP speaker with LED display and flasher leverage the VoIP Communication solution to extend tele-presence with enhanced audio for those environments where network-wide communication is desired and that require large speakers with high output to overcome high ambient noise areas or large spaces.
AtlasIED IP-SDMFLED registers as a communication endpoint directly within InformaCast, and SA-Announce Advanced Notification applications, supporting both visual text and audio broadcast to enhance physical security while improving day-to-day communications through advanced alerting, bell schedules, pre-recorded, & scheduled announcements, while leveraging the WAN/LAN Network Architecture.
Features
-
Network Features
-
Dynamic or Static IP Address
-
IEEE802.3 10/100Base-T Ethernet
-
IEEE 802.1q Tagging
-
IEEE 802.11AT Compliant
-
VoIP Standard Audio: G.711 u-law/a-law (64 kbit/s) or G.722 Wideband Audio (64 kbit/s)
-
Auto Registration: SLP for Singlewire Applications, DHCP Option 72 for Syn-Apps' Applications or IEDNet+ for AtlasIED Applications
-
Static Registration: HTTP GUI for Static Configuration
-
Audio Features
-
Integrated Amplifier 15-Watt Total Power: Primary Speaker Output 8 ohm
-
Aux Audio Line-In Balanced (2.8Vpp 10K)
-
Aux Audio Line-Out Balanced (2.8Vpp 10K)
-
Additional Features
-
2 General Purpose Inputs
-
PoE+Enabled
-
1 General Purpose Output (2A @ 30 VDC)
-
Phone/Night Loud Ringer
-
External Power Supply Option
Specifications
Speaker Type | Coaxial |
Speaker Size | 8" LF, 1" HF |
Frequency Response | 86Hz - 15.5kHz |
Dispersion | 105˚ (2kHz Octave Band, -6dB Points) |
Sensitivity | 98dB SPL Average |
Power Rating | 12-Watts Max (802.3AF) / 25-Watts Max (802.3AT) |
THD | <0.2% |
Grille | Powder Coated Steel |
Connector Type | RJ-45 |
Height | 14.37" (365mm) |
Depth | 3.42" (87mm) |
Width | 12.87" (327mm) |
Safety Listed | 62368-1, CSA C22.2 #62368-1, IEC 62368-1 CB Scheme and FCC |
Shipping Weight | 6.37 lbs (2.89kgs) |
