Product Description
Atlas Sound FAP42TCEN EN54-24 Certified 4" Shallow Mount Coaxial In-Ceiling Speaker with 16-Watt 70/100V Transformer
Overview
The EN54-24 certified FAP42TCEN's 130° dispersion angle effectively reduces the number of loudspeakers necessary to achieve coverage in distributed systems with low ceilings. The loudspeaker component matches the performance of the legendary AtlasIED Strategy FA Series. High quality construction 4" coaxial cone type driver includes a 1" voice coil and polypropylene cone with a butyl rubber surround. The 19mm coaxially mounted tweeter is constructed of PEI. This loudspeaker is factory assembled in a deep drawn enclosure and includes a specially designed 16 watt low saturation, 70.7V / 100V transformer. A convenient front mounted selector switch allows tap selection without the need to remove the speaker from the ceiling. This switch also includes a transformer bypass setting for 8Ω operation.
Features
-
"Press Fit" Grilles Blend Better into Contemporary Architecture
-
Easy Installation in Drop Tile or Sheetrock Ceilings via C-ring/V-rail Tile Bridge and "Dog Leg" Mounting System (Included)
-
Enhanced Quality 70.7V/100V Internal Transformers Minimize Insertion Loss and Maintain Low Frequency Response While Providing increased Output for Higher SPL Applications
-
Front Mounted Tap Selector Switch for Easy System Tuning Adjustments Includes Transformer Bypass Setting for 8 ohm Direct Coupled Operation
-
Low Depth (4") Speaker System for Limited Space Applications
-
EN54-24 Certified
-
ISO 7240-24 Certified
-
Ingress Protection (EN54-24): IP21C
Specifications
Speaker Type | Coaxial |
Sensitivity | (1W/1m): 88dB |
Sensitivity (EN54-24) | (1W/4m): 70dB |
Power Taps | 1, 2, 4, 8, 16 Watts & 8Ω |
Frequency Response | 83Hz - 20kHz (±5dB) |
Dispersion | 130° |
Depth | 4.33" (110mm) |
Diameter | 10.43" (265mm) |
Cut Out Diameter | 9" (229 mm) |
Shipping Weight | 10.68 lbs (4.84 kgs) |
