Product Description
Atlas Sound ECM-20 20A AC Power Conditioner and Spike Suppressor
The Atlas Power ECM-20 is a 20A Power Conditioner and AC Spike Suppressor that is designed to be used as a standalone unit or in conjunction with an ECS unit up to 1000ft away. The ECM-20 features AC Spike and Surge Suppression, AC Mains Voltage monitoring, EVS circuitry, and Remote Activation.
The ECM-20 is designed to be conveniently housed in the ECM-RACEWY6 for the addition of multiple outlets directly connected to the AC mains from the electrical panel.
- 2 Outlets, 20A
- Manual/Auto On/Off Switch
- Incoming AC Present LED
- Active LED
- Clamping Spike & Surge Suppression
- AC Mains Voltage Monitoring
- Radio Frequency and Electromagnetic Interference Filtering
| CURRENT RATING | 20 Amps |
| POWER REQUIREMENT | 120V 60Hz |
| CERTIFIED TO SAFETY LISTING | MET (UL 1449) |
| OPERATING VOLTAGE | 102-132VAC |
| MINIMUM SPIKE CLAMPING VOLTAGE | 460 VRMS @ 3000A |
| MAXIMUM SPIKE CLAMPING VOLTAGE | 6,000V |
| POWER CONSUMPTION | .5 Watts |
| HEIGHT | 3.0" (76.2mm) |
| WIDTH | 8.5" (215.9mm) |
| DEPTH | 3.5" (88.9mm) |
| WEIGHT | 1.25 lbs. (.68 kg) |
