Product Description
Atlas Sound CLA202 2-Channel 200W 1RU Power Share Amplifier
Overview
The AtlasIED CLA202 is a two-channel, 200W multi-impedance amplifier featuring AtlasIED's Patent-Pending Power Share technology. This innovative feature allows precise control of power levels across different zones regardless of the load impedance.
Designed for versatility, the CLA202 amplifier is suitable for both commercial 25V/70.7V/100V distributed systems and sound reinforcement applications requiring amplification for low impedance loads like 2, 4, or 8 ohms. Its switch-mode, global auto-sensing power supply ensures stable output under varying power conditions. The amplifier's output stage is designed for exceptional dynamic performance, delivering high voltage and current simultaneously to virtually any loudspeaker load.
Configuring each channel's Power Share level and speaker load is straightforward with the CLA amplifier, using switches on the rear panel. Additional features include a low-resistance, direct-coupled thermal transfer design for optimal temperature management and Energy Star compliance for energy efficiency.
Whether for large distributed constant voltage sound systems, high SPL sound reinforcement, or both, the AtlasIED CLA Series offers a versatile, high-power solution.
Features
- 2 Amplifier Channels
- Load Configurations - Each Channel Configured Individually 2Ω, 4Ω, 8Ω, 25V, 70.7V, & 100V
- Power Share Configurations
- 2 x 100W
- 1 x 175W / 25W
- 1 x 150W / 50W
- 1 x 125W / 75W
- Energy Efficient 1W Standby GPI
- Convection Cooling, Fan Assist On Demand
- Priority Mute GPI
- Rear Attenuators
- Remote Level Control
- Compact 1RU, Half Rack
- Patent Pending
Specifications
- Type: 2 Channel Power Amplifier
- Topology: Class D
- Output Power: 200W
- # Inputs: 2
- GPI Ports: 5, Euro Block 3.5mm
- Output Speaker Terminals: 2, Removable Euro Block, 5.08mm Pitch, Locking
- THD 1kHz And 1dB Below Rated Power: ≤0.15%
- Signal To Noise Ratio 8 Ohm: >93dBA Below Rated Output (A-Weighted)
- Cooling: Idle Mode: Convection, Audio Signal Sense: Fan, Variable
- Rack Space: 1 RU, 8.5" Wide (half rack)
- Dimensions (HxWxD): 1.75" x 8.75" x 13.5" (44mm x 222mm x 343mm)
- Shipping Dimensions (HxWxD): 4.5" x 17.25" x 11.75" (114mm x 438mm x 298mm)
- Weight: 5.3 lbs. (2.36kg)
