Product Description
Atlas Sound C5AT70 8-inch Dual Cone In-Ceiling Speaker
Model C5AT70 is a reliable, economically priced 15-watt speaker with a pre-mounted 70.7V 5W transformer that offers many features found in speakers costing considerably more.
It includes a curvelinear, treated-paper cone for lower harmonic distortion. It is also equipped with a full 1" diameter copper voice coil with a black-anodized aluminum former for better power dissipation.
Model C5A operates within a frequency response range of 50Hz - 18kHz with a sensitivity of 96dB and a dispersion angle of 105°.
It mounts a wide variety of AtlasIED round and square baffles and enclosures to meet functional and aesthetic application requirements.
Features
- Ideal for Multi-Purpose Commercial, Industrial and Institutional Use
- Industry Standard Value Loudspeaker with Proven Performance
- Mounts a Wide Selection of Atlas Sound Baffles
- With Factory-Installed LT-70 Line-Matching Transformer
Specs
| SPEAKER TYPE | Treated Paper |
| SENSITIVITY | 96dB Peak, 93dB Average |
| FREQUENCY RESPONSE | 100Hz - 10kHz |
| POWER TAPS | .5, 1, 2, & 5 Watts |
| DISPERSION | 105° |
| DEPTH | 2 5/8" (6.6675 cm) |
| DIAMETER | 8" (20.32 cm) |
| SHIPPING WEIGHT | 2.17 lbs (0.98 kgs) |
