Product Description
Atlas Sound AS-5T Two-Way, 5", Full Range, Surface Mount Loudspeaker
Overview
The AtlasIED AS-5T is a compact, weather-resistant, surface-mount loudspeaker designed for versatile sound reinforcement applications that require durability, modern aesthetics, and exceptional sonic performance.
It features a high-excursion 5.25" polypropylene woofer and a 1" silk dome, ferrofluid-cooled high-frequency driver, delivering consistent and accurate broadband frequency response on and off axis.
Available in black or white, the high-impact ABS enclosure with UV inhibitor is highly durable and scuff-resistant, ensuring reliable performance indoors and outdoors (IP55 rated).
Installation is straightforward with the included slip-free yoke mount, optional universal mount, or compatibility with third-party VESA mounts.
Equipped with a low-insertion-loss 30W transformer for 70V or 100V distributed systems, wattage tap selection and low-impedance bypass are easily adjustable via a rear-mounted slide selector switch with a security cover.
The AS-5T is acoustically matched with the broader AS Series, ensuring consistency in mixed-product installations.
Features
- Minimalistic and clean industrial design for sensitive architectural constraints
- Effective coverage for systems with space limitations
- Extremely consistent off axis performance
- Ultra-low insertion loss 30W transformer for dynamic performance in distributed systems
- High impact ABS enclosure with UV inhibitor
- IP55 & UL1480A rated
- Slip-Free yoke mount supplied. Optional pan and tilt bracket.
- Compatible with VESA™ mounts
- Advanced tunings available via AtlasIED Atmosphere DSP platform
Includes
- 1x AtlasIED AS-5T 5.25-Inch AS Series Surface Mount Loudspeaker
- 1x Slip Free U-Bracket
Specifications
- Type: Two-Way, Full Range, Surface Mount Loudspeaker
- Frequency Range (-10dB): 63Hz-20kHz
- Frequency Response (+/- 3dB): 95Hz-20kHz
- System Sensitivity (1W @ 1m): 87dB
- Nominal Coverage Angle (HxV -6dB): 120° x 120°
- Power Handling
- Average: 100W
- Programme: 200W
- Peak: 400W
- Recommended Amplifier Power: 200W @ 8 Ohmss
- Nominal Impedance: 8 Ohms (Min 7.4 Ohms)
- Rated Maximum SPL
- Average: 107dB
- Peak: 113dB
- With Max. Transformer Tap - Average: 102dB
- Transformer Taps- via slide selector switch: 30W, 15W, 7.5W, 3.8W ( 1.9W 70V) & Low Z operation
- Directivity Index (dB): 7.3
- Transducer
- Low Frequency: 5.25" (130mm) Polypropylene, Butyl Rubber surround
- High Frequency: 1" (25mm), Silk Dome, Ferrofluid Cooled, PPT Protection
- Physical
- Enclosure: High Impact ABS UL-V0
- Grille Material: Aluminum, Powder Coated
- Connectors: Euroblock with screw connections and loop output
- Safety Agency Rating: UL1480A, CE
- Ingress Protection: IP55
- Operating Temperature: -40°F to 140°F (-40°C to 60°C)
- Product Dimensions (HxWxD): 10.9" x 6.88" x 7.6" (276.9mm x 174.8mm x 193.0mm)
- Net Weight - (per unit): 9.28 lbs (4.21kg)
- Color variations: black or white
