Product Description
Atlas Sound 12CXT60 12-inch 250W Coaxial In-Ceiling Speaker
Model 12CXT60 is a 250 watt speaker that combines a 12" diameter, low frequency transducer and a 1" exit, true compression driver. With the addition of a factory installed, high efficiency, 60W, 70.7/100V step down line transformer.
The unit features a curvilinear, treated paper cone for lower harmonic distortion and a built-in crossover network for proper frequency transition between the two reproducers.
Model 12CXT60 operates within a frequency response range of 45Hz -18kHz with a sensitivity of 99dB and a dispersion angle of 90° (-6dB/2kHz octave band).
Features
- 1" Exit Compression Driver Coupled to a Specially Designed Conical Wave-Guide Horn
- 90 Degree Conical Dispersion (2 kHz Octave Band)
- High Efficiency Cone Woofer Optimally Matched to High Frequency Device via a Specially Designed Crossover to Insure Even Transition
- Perfectly Suited for Use with Atlas Sound "Q" Series Enclosures
Specs
| FREQUENCY RESPONSE | 45Hz - 18kHz |
| SENSITIVITY | 95.5dB (1W/1m) Average |
| POWER TAPS | 7.5, 15, 30, 60 |
| SPEAKER TYPE | Compression Driver Coaxial |
| DISPERSION | 90° |
| DEPTH | 8" (20.32 cm) |
| SHIPPING WEIGHT | 27.00 lbs (12.27 kgs) |
