Product Description
Astera FP2-Individual Helios Tube Light (1.8', Basic Kit)
Overview
This Kit features the Astera Helios Tube RGB LED Tube Light and a set of mounting accessories to provide you with an introduction to this unique light source. Included are a 1.8' Helios tube, a floor-mounted stand to position the tube vertically, two eyebolts to hang the light with wire or cable, and two metal holders to secure the tube to a truss section. An AC adapter is not included with the kit and must be purchased separately for use.
This kit includes: Helios Tube™:36W power, 8 pixel segments, 180° beam angle, IR, App controlled, wired & wireless (CRMX) DMX, built-in rechargeable LG battery, IP65. Incl’s stand, 2 eye bolts, 2holders. (Individual power supply *not included).
Astera Helios Tube RGB LED Tube Light (1.8')
With a wide 120° beam spread, the Astera Helios Tube RGB LED Tube Light will create a soft direct light on your subject and can be used as an accent light or as a design element either on location or on set. Suitable for cine, theatrical, and event productions, the wireless tube is powered by an integrated battery that will give you 20 hours of runtime on a three-hour charge. The light outputs up to 393 lux at 3.3' (4000K) and features eight LED emitters in a 1.8' long tube. It allows mounting in areas where a Titan Tube wouldn't fit, so you can mount into a set, onto a stand, hang it from a grid, or even hold in your bare hand. The Helios Tube has impressive CRI/TLCI ratings of 96/96 to indicate high accuracy in the rendition of color. It uses RGB, mint, and amber LEDs as well as hue, saturation, and intensity control to access millions of custom colors.
Color and control are at the heart of the Helios Tube's design. The tube has an expansive white light color temperature range of 1750 to 20,000K to seamlessly blend into any ambient light situation or just exercise creative expression. You can make adjustments locally on the fixture or remotely via a console with the Helios Tube wired to it. Wireless DMX, CRMX, and other types of units can adjust functions at distances up to 990'. There's also an AsteraApp that lets you control the light with Bluetooth and IR control via an optional remote. The Helios Tube ships without a power supply so you can choose between an optional AC adapter/charger or a PowerBox.
Control
- You can use the Astera infrared remote control (not included) by simply pointing it at individual lights to set the desired effect.
- The downloadable AsteraApp is an efficient way to quickly create a customized light show using your smart device. It can group several lights together, address individual lights or groups of lights, and send complex effects with a user-defined color palette to all lights in the range.
- The light can also be controlled by CRMX (wireless DMX), as the built-in receiver is compatible with all LumenRadio CRMX transmitters.
Wireless Modules
- 865 to 870 MHz
- 902 to 928 MHz
- 2.4 GHz
TruColor Calibration
Tunable White
Green/Magenta Correction
20-Hour Runtime
Effects
Talkback +
Anti-Theft
Flicker-Free Filming
Scheduled Standby Mode
DJ Application
Dynamic Power Boost
Emergency Lights
Other Features
Astera Titan Tube Single Unit Accessory Kit
The Titan Tube Single Unit Accessory Kit from Astera offers mounting options for the tube The kit includes a folding floor stand to hold the tube vertically, two Eyebolts for suspending the tube with wire or cable, and two metal holders for securing the tube to a truss section.
Specifications
Astera Helios Tube RGB LED Tube Light (1.8')
Item Type | 1 x LED Light Tube/Wand |
Included Storage Case | None |
Lumens | 1285 (at 3200K) 1340 (at 4000K) |
Photometrics | 3200K: 33 fc / 360 Lux at 3.3' / 1 m* 4000K: 36 fc / 393 Lux at 3.3' / 1 m* *Standardized Measurement Supplied by the Manufacturer |
Color Temperature | 1750 to 20,000K |
Color Modes | RGB |
Color Accuracy Standard | CRI 96 TLCI 96 |
Cooling System | Passive |
Dimming | Yes, Built-In Dimmer |
Expected Lamp Life | 50,000 Hours |
Beam Angle | 120° |
Built-In Flash | No |
Umbrella Mount | No |
Front Accessory Mount | None |
Wireless Remote Control Type | Wi-Fi Wireless CRMX Wireless DMX |
Mobile App Compatible | Yes: Android & iOS App Name: AsteraApp Functionality: Remote Control, Setup *As of December, 2022: Check with manufacturer for the most up-to-date compatibility |
Wireless Range | 984.3' / 300 m |
Power Source | Battery (Built-In) AC to DC Adapter (Not Included) |
Inputs/Outputs | 1 x Barrel / Coax (2.1 x 5.5 mm) Power Input (24 VDC) |
Battery | 1 x Rechargeable (Built-In) • Up to 20-Hour Runtime • 3-Hour Charge Time |
Battery Charging | 1 x AC to DC Adapter (Not Included) |
AC Input Power | 90 to 240 VAC, 50 / 60 Hz |
DC Input Power | 24 VDC at 1.25 A |
Inline Switch | No |
Power Pass-Thru | No |
Power Consumption | 24 W |
Fixture Mounting | 2 x M5 Female Thread |
Environmental Protection | Advertised as Weather Resistant *Manufacturer Testing: IP65 |
IP Rating | IP65 |
Operating Temperature | 32 to 104°F / 0 to 40°C |
Operating Humidity | 0 to 100% |
Display | Yes |
Materials | Metal, Polycarbonate (Housing) |
Dimensions | 21.6 x 1.6" / 54.9 x 4.1 cm (Fixture) |
Weight | 1.69 lb / 0.77 kg |
