Product Description
Astera AX9-Octo Set with Charging Plate and Road Case
AX9-Octo Set: Qty 8 AX9 units, One 8 Unit charging plate, 9 True1 power cords for the charging plate, and one road case for 8 units. (Packaged and shipped separately, Not assembled)
Overview
This AX9 Octo Set from Astera outfits you with eight AX9 PowerPAR lights, a charging plate, and a road case to take it all on the go. Create the ultimate set lighting configuration thanks to the powerful Titan LED engine lights. The charging plate simultaneously charges all eight lights when depleted and fits inside the included case. A single powerCON TRUE1 cable runs power to the plate.
Astera AX9 PowerPAR
The AX9 PowerPAR from Astera is a powerful 3-in-1 light that can be used as a wireless light, an uplight, or a wired PAR light, depending on your needs. Its Titan LED engine is powered by rechargeable batteries and has a 13° beam angle. A CRI rating of 96 ensures accurate color reproduction. Controlling the brightness and color of the light can be achieved in multiple ways, one of which is the onboard OLED display and buttons.
Both wired and wireless DMX connections allow for integration into preexisting communication networks. Bluetooth connectivity makes the light compatible with the AsteraApp for additional features and controls. The included bracket is removable and features a 3/8"-16 thread and 1/2" hole for mounting. Four M6 threads provide additional mounting options when the bracket is detached. Included with the AX9 are two filters for increased control over the light's intensity.
Astera 8-Bay Charging Plate for AX9 PowerPAR
This 8-Bay Charging Plate from Astera lets you simultaneously charge eight AX9 PowerPAR 3-in-1 LED lights. Designed for in-case charging and flight cases, this plate features contactless charging operation.
Features
- Detect all available lights, set them up, check their status, and configure DMX addresses and profiles with Talkback+
- Set the length of your production and ensure the lights won't right out while getting maximum brightness
- Individually calibrated lights for consistency and exact reproduction
- Build programs out of colors and effects, trigger them, or set them to a beat
- Scrambled PWM technology to avoid flickering when filming
- Adjust green/magenta during content creation to reduce postproduction work
- Switch lights into power-saving standby and schedule them to wake up when production starts
- PowerBoost feature displays maximum brightness and intensifies colors
- Switches to white light when AC power is cut for emergency lighting
- Lights give a visual and audible alarm when moved during an event as well as notify AsteraApp
- DJ feature with auto BPM analyzes song beat and matches programs to it
- AsteraApp had additional items and features frequently added via software updates
Specifications
Astera AX9 PowerPAR
| Colors | RGB, Mint, Amber |
| LED Power | 105 W |
| Power Draw | 70 W |
| Lumens | 2497 Lumens at 2700K 3008 Lumens at 3200K 2891 Lumens at 5500K |
| CRI | ≥96 |
| Beam Angle | 13° |
| Strobe | 0 to 25 Hz |
| Battery Lifetime | 70% After 300 Cycles |
| Battery Runtime | 20 Hours |
| Charging Time | 5 Hours |
| AC Input | 100-240 VAC, 50/60 Hz |
| Inputs/Outputs | 1 x PowerCON True1 Input 1 x PowerCON True1 Output 1 x 5-Pin XLR DMX Input 1 x 5-Pin XLR DMX Output |
| Mounting | 4 x M6 Thread |
| Wireless Frequency | CRMX 2.4 GHz, UHF Bluetooth 3/3.3 |
| Bluetooth Range | 984.3' / 300 m |
| Housing Material | Aluminum |
| IP Rating | IP65 |
| Ambient Temperature | 32 to 104°F / 0 to 40°C |
| Weight | 12.5 lb / 5.66 kg |
| Dimensions | 6.9 x 8.7 x 10.1" / 175 x 222 x 256 mm |
Astera 8-Bay Charging Plate For AX9 PowerPAR
| AC Input Power | 115 to 230 VAC, 50 / 60 Hz at 5.8 to 11.6 A |
| Number of Battery Bays | 8 |
| Output Voltage | 25.5 VDC |
| Dimensions | 28.1 x 22 x 6.2" / 715 x 558 x 157 mm |
| Weight | 25.02 lb / 11.35 kg |
