Product Description
Astera AX5 TriplePAR LED Fixture
Overview
For those who need a powerful battery-powered fixture that can operate for up to 20 hours per charge, the Astera AX5 TriplePAR is an RGBAW LED fixture with 3 x LED emitters and a 13° beam spread. The RGBA fixture supports a color temperature range of 2480 to 7100K when controlled via the app or DMX, and features a CRI rating of up to 92. In addition, the fixture is dimmable from 100 to 0% brightness in any mode. The fixture has an integrated lithium-ion battery, which can run the fixture for up to 20 hours on a full charge, while requiring up to 7 hours to charge.
As you would expect with an RGBAW fixture, it supports a variety of effects, including color, fire, strobe (flash), and LEE gel color matching. The fixture can be controlled via wired or wireless DMX (supports LumenRadio) as well as via the AsteraApp, or an optional IR remote. The light features a removable yoke, and an integrated pop-out Kickstand. The bracket features a 3/8" threaded hole for attaching mounting options.
Remote Control
Status Screen
- Solid (static) Color
- Color Fade
- Color Chase
- Running Lights
- Fire Effect
- Rainbow Effect
- Lee Gel Effects
Flicker Control
Shipping Mode
Features
- 13° Beam Spread
- 3 x RGBAW LED Emitters
- Variable Color Temperature: 2480-7100K
- 92 CRI
- 0 to 100% Dimmable
- Battery Powered, 20-Hour Runtime
- Built-In LEE Filter Compatibility
- RGB Effect Mode, Strobe Mode
- Wired/Wireless DMX, IR, and APP Control
- Removable Yoke, Pop-Out Kickstand
Specifications
| LED Power | 45 W |
| LEDs | 3 x 15 W RGBAW LED Emitters |
| Luminous Flux | 1080 Lumens at 4000K |
| Beam Angle | 13° |
| CRI | 92 |
| Strobe | 0 to 25 Hz |
| Wired DMX | Input: 5-Pin XLR Output: 5-Pin XLR |
| Wireless | Frequency EU: 868.0 to 869.7 MHz US: 902 to 928 MHz 2.4 GHz Range 984.25' / 300 m |
| Material of Construction | Aluminum |
| Battery | Chemistry: Lithium-Ion Runtime: 20 Hours Lifetime: 70% After 300 Cycles Charging Time: Up to 7 Hours |
| Input Voltage / Frequency | 90 to 264 VAC, 47 to 63 Hz |
| Current | Input: 115 VAC, 1.8 A / 230 VAC, 1 A |
| Power Connector | In: 1 x Neutrik True 1 powerCON Output: 1 x Neutrik True 1 powerCON |
| Operating temperature | 32 to 104°F / 0 to 40°C |
| Relative Humidity | 0 to 100% |
| IP Rating | 65 |
| Dimensions | With Bracket: 8.41 x 7.62 x 5.83" / 21.35 x 19.36 x 14.81 cm Without Bracket: ⌀6.03 x 5.53" / ⌀15.32 x 14.05 cm |
| Weight | 7.5 lb / 3.4 kg |
| Package Weight | 9.035 lb |
| Box Dimensions (LxWxH) | 11.4 x 9.7 x 8" |
