Product Description
Ashly Audio AQM408 Aqua Control DSP Matrix/Speaker Processor
Overview
The Ashly Audio AQM408 is an advanced, stand-alone speaker processor and zone mixer designed for use with external amplification, providing the power and flexibility to handle diverse audio situations.
Powered by the AquaControl DSP engine, first seen in the mXa1502, the AQM408 offers a comprehensive library of DSP functions through a versatile and intuitive user interface. It connects to any browser-enabled device via LAN or Internet, enabling convenient remote access for configuration and troubleshooting from virtually anywhere.
With its 4-input by 8-output configuration, the AQM408 is suitable for a wide range of applications, from small zone setups to stadium PA systems.
Features
- Remote Access From Anywhere In The World
- Intuitive and easy to use AquaControl software, no training required
- Next generation DSP for speaker processing and multi-zone
Specifications
- Number of Input Channels: 4 Balanced Line
- Number of Output Channels: 8 Balanced Line
- Distortion (THD-N, typical):
- Signal-to-Noise: >110dB (20Hz-20kHz) unweighted
- Frequency Response: 20Hz-20kHz, ±0.25dB
- Balanced Input Connector: XLR
- Input Impedance: 10k Ohms
- Propagation Delay: 1.08 ms
- ADC/DSP/DAC Resolution: 32-Bit
- Sample Rate: 48kHz
- Environmental: 40°-120°F (4°-49°C), 150°F (65.5°C) max - not for long term use
- AC Mains Nominal Voltage Input: 90 - 240VAC, 50/60Hz
- AC Mains Operating Range: 70 - 270VAC
- AC Mains Line Cord Connector: Detachable Nema 5-15 for USA
- Control Network: RJ-45 connector, 1GB Ethernet
- Line Output Connector: Balanced XLR
- Line Output Maximum Level: +20.5 dBu
- Remote DC Level Control: Euroblock 3.5mm - Gnd, CV, V+ per each of the 3 VCA inputs
- Unit Dimensions: 19"W x 1.75"H x 8.5"D (483mm x 45mm x 216mm)
- Shipping Dimensions: 23"W x 4.5"H x 12.5"D (584mm x 114mm x 318mm)
- Unit Weight: 6.2lbs (2.8kg)
- Shipping Weight: 9lbs (4.1kg)
- 5 year warranty
