Product Description
ADJ MEDIA OPERATOR BT Media Operator BT 1RU Bluetooth Media Player/Mixer
The American Audio, Media Operator BT is a fast, simple and reliable all-in-one MP3/Wireless Audio media player designed for permanent installations where easy control of music is a must (ie. restaurants, fitness studios, retail locations, etc.) and great for mobile entertainers as well. The Media Operator BT offers digital playback from Memory Cards or USB sticks/drives.
The Media Operator BT includes full MP3 playback control as well as a microphone input (XLR / 1/4” combo), master volume control and 3x line output options. Plug the unit directly into powered speakers, an amplifier or secondary mixer through the balanced XLR, 1/4" or stereo RCA outputs.
Sku #: MED155
Features
- Memory Card* / USB 2.0 / Wireless Audio full functioning MP3 Player
- Track Time Display
- Track Search Buttons
- Easy-to-use
- Bright LCD Display
- Reads standard or High Capacity Memory cards up to 32GB
- Up to 1000 MP3 songs on a 1G Memory Card** (MP3 recorded at 128bit rate**)
- 4x RCA line Inputs and 1x 35mm Auxiliary Jack Input
- 1x RCA, 1x L/R Unbalanced 1/4” Jack, 1x L/R Balanced XLR Outputs
- Master music output volume control
- Individual EQ Treble / EQ Bass control for Music
- Combo Mic input: 1/4” jack and XLR
- Master mic output volume control
- Individual EQ Treble / EQ Bass control for Mic
- Voltage Selector Switch: 115V or 230V 50/60Hz
- Dimensions (L x W x H): 19” x 4” x 1.75” in. / 483 x 193 x 44 mm (1 rack space)
- Weight: 4 lb. / 1.7 kg.
*Memory Card is not Included
**Capacity may vary
Specs
Supported Multimedia Input Formats
- Memory Card
- USB Flash Drives
- Wireless Audio Devices
Connections
- (4) RCA Stereo Line Inputs (L / R)
- (1) 3.5mm Mini-Stereo Input
- (1) RCA Stereo Line Output (L / R)
- (1) ¼” Unbalanced Output (L / R)
- (1) XLR Balanced Output (L / R)
- (1) AC Power Input
- (1) Multi-Voltage Power Supply Switch (115V / 230V)
Electrical
- Frequency Response: 20Hz - 20KHz ±0.5dB
- Input Sensitivity: 1V
- (A-W RMS) S/N Ratio: 100dBA
- THD: 1%
- SMPTE: 0.1%
- Input Impedance: 20KHz (Balanced) 10KHz (unbalanced)
- (5Hz-1KHz) Damping Factor: >200
- Slew Rate: 20V/US
- Input Voltage: AC110-230V 50Hz - 60Hz
