Product Description
Allen & Heath AH-XB2-14 Compact Broadcast Mixer
The AH-XB2-14 offers a host of specialized broadcast features that normally come at a much higher price, including telephone communication (telco) channels, mic channel ON switch sensing, stereo channel start/cue outputs for playback device control, automatic muting of speaker outputs and much more. The AH-XB2-14 incorporates new features and styling based on feedback from the many broadcasters who have built their operations around the original XB-14. With a wealth of routing options, dual stereo channels for up to 7 stereo sources, and the addition of a dedicated Audition bus, enhanced microphone preamps and stereo channel gain range, XB-142 satisfies the demands of small radio and internet broadcasters as well as larger studios with multiple rooms. With no less than 27 logic I/O for remote control and 15 configuration switches, XB-142 is a highly flexible solution.
Features
- 4 mic/line channels
- 4 Dual Source stereo channels
- 2 Telco channels
- HPF and 3-band, swept mid EQ on mono channels
- 2-band EQ on stereo channels
- Variable high pass / low pass filters on Telco channels
- Smooth-ride 100mm faders
- 2-stage, padless pre-amp design
- Fader-start sensing on mono channels
- Start/cue logic outputs on stereo channels
- External meter socket
- Separate headphones mix for engineer/producer and 2 guests
- Auto mutes on control room outputs
- Remote mute facility on mic channels
- Configurable USB stereo audio in/out
- Audition bus for auditioning and off-air recording
- Aux and separate stereo busses for processing/recording
- XLR main outputs with inserts
- Input signal and peak metering
| Inputs | - Mono Channel Mic Input (XLR): +6 to -63 dBu nominal / +17 dBu max
- Mono Channel Line Input (TRS Jack Socket): +10 to -26 dBu / +30 dBu max
- Insert Point (TRS Jack Socket): 0 dBu nominal / +21 dBu max
- Stereo Input (TRS Jack Sockets): 0 dBu nominal (control = off to +10 dBu)
- Stereo Input (RCA Phono Sockets): 0 dBu nominal (control = off to +10 dBu)
- Telco Channel Input (XLR): +10 to -26 dBu / +30 dBu max
|
| Outputs | - PGM L/R Outpu(XLR): +4 dBu nominal / +25 dBu max
- PGM Mono Output (RCA Phono): 0 dBu nominal / +21 dBu max
- PGM L & R inserts (TRS Jack Sockets): -2 dBu nominal / +21dBu max
- Aux Output (Jack Socket): 0 dBu nominal / +21 dBu max
- Mix B Outputs (RCA Phono Sockets): 0 dBu nominal / +21 dBu max
- Audition Outputs (RCA Phono Sockets): 0 dBu nominal / +21 dBu max
- CRM Outputs (RCA Phono Sockets): 0 dBu nominal / +21 dBu max
- Telco Output (XLR): 0 dBu nominal / +21 dBu max
|
| THD + N | - Mic In to PGM L/R Out: < 0.01% (0 dB Gain, 1 kHz, +10 dBu out)
- Mic In to PGM Out: < 0.01% (30 dB gain, 1 kHz, +10 dBu out)
- Line In to PGM L/R Out: < 0.01% (0 dB gain, 1 kHz, 0 dBu out)
- Stereo In to PGM Out: < 0.01% (0 dB gain, 1 kHz, +10 dBu out)
|
| USB Audio Codec | - USB Audio In/Out: USB 1.1 compliant / 16-bit
- Sample Rate: 32, 44.1, 48 kHz
|
| Noise | - Mic Pre EIN @ Maximum Gain: -124 dBu (150 R Input Z, 22 Hz to 22 kHz)
- PGM Out: < -100 dBu (PGM fader = 0, 22 Hz to 22 kHz)
- Audition Out: < -100 dBu (mix B out = 0, 22 Hz to 22 kHz)
- Aux Out: < -85 dBu (mono out = 0, 22 Hz to 22 kHz)
|
| Headroom | - Analog Headroom from Nominal (O VU) Outputs: 21 dB
- Analog Headroom from Nominal (O VU) Mix Point: 24 dB
- Headroom from Nominal (O VU): 14 dB
|
| Crosstalk / Attenuation | - Mono Fader Attenuation: -95 / -95 (dB relative to +10 dBu, 1 kHz to 10 kHz)
- Mono ON Switch Attenuation: -95 / -95 (dB relative to +10 dBu, 1 kHz to 10 kHz)
- TELCO Fader Attenuation: -95 / -95 (dB relative to +10 dBu, 1 kHz to 10 kHz)
- TELCO ON Switch Attenuation: -95 / -95 (dB relative to +10 dBu, 1 kHz to 10 kHz)
- Stereo Fader Attenuation: -95 / -90 (dB relative to +10 dBu, 1 kHz to 10 kHz)
- Stereo ON Switch Attenuation: -95 / -95 (dB relative to +10 dBu, 1 kHz to 10 kHz)
- PGM Fader Attenuation: -100 / -95 (dB relative to +10 dBu, 1 kHz to 10 kHz)
- TELCO Clean-Feed Isolation from I/P: -55 / -40 (dB relative to +10 dBu, 1 kHz to 10 kHz)
- Stereo Separation, L in to PGM R Out: -70 / -50 (dBr, 1 kHz to 10 kHz)
|
| Frequency Response | - Microphone In to PGM L/R Out: +0.5 / -1 dB, 10 Hz to 30 kHz (30 dB gain)
- Line In to PGM L/R Out: +0.5 / -1 dB, 10 Hz to 20 kHz (0 dB gain)
- Stereo In to PGM L/R Out: +0.5 / -1 dB, 10 Hz to 30 kHz
|
| Power Supply | |
| Power Consumption | |
| Fuse Rating | |
| Dimensions (W x H x D) | - 15.2 x 4.1 x 18.3" / 385 x 103 x 465 mm
|
| Weight | |
Please note that this item works with the AH-ZED14-RK19.
Other Details
Limited One Year Manufacturer’s Warranty
Allen & Heath warrants the Allen &Heath -branded hardware product and accessories contained in the original packaging ("Allen & Heath Product”) against defects in materials and workmanship when used in accordance with Allen & Heath's user manuals, technical specifications and other Allen & Heath product published guidelines for a period of ONE (1) YEAR from the date of original purchase by the end-user purchaser ("Warranty Period"). This warranty does not apply to any non-Allen & Heath branded hardware products or any software, even if packaged or sold with Allen & Heath hardware. Please refer to the licensing agreement accompanying the software for details of your rights with respect to the use of software (“EULA”).
Repair or replacement under the terms of the warranty does not provide right to extension or renewal of the warranty period. Repair or direct replacement of the product under the terms of this warranty may be fulfilled with functionally equivalent service exchange units.
This warranty is not transferable. This warranty will be the purchaser’s sole and exclusive remedy and neither Allen & Heath nor its approved service centers shall be liable for any incidental or consequential damages or breach of any express or implied warranty of this product.
Conditions of Warranty
The equipment has not been subject to misuse either intended or accidental, neglect, or alteration other than as described in the User Guide or Service Manual, or approved by Allen & Heath. The warranty does not cover fader wear and tear. Any necessary adjustment, alteration or repair has been carried out by an authorized Allen & Heath distributor or agent. The defective unit is to be returned carriage prepaid to the place of purchase, an authorized Allen & Heath distributor or agent with proof of purchase. Please discuss this with the distributor or the agent before shipping. Units returned should be packed in the original carton to avoid transit damage. DISCLAIMER: Allen & Heath shall not be liable for the loss of any saved/stored data in products that are either repaired or replaced. Check with your Allen & Heath distributor or agent for any additional warranty information which may apply. If further assistance is required please contact Allen & Heath Ltd. Any changes or modifications to the equipment not approved by Allen & Heath could void the compliance of the product and therefore the user’s authority to operate it.
