Product Description
Allen & Heath AH-ME-1 Personal Monitor Mixer
ME-1 is probably the most sophisticated personal mixer on the market, giving precision control over up to 40 channels to satisfy the most demanding ears.
Features
- 40 Inputs with level and pan control
- Dimmable OLED screen
- 16 Assignable keys
- 3.5mm and 1/4” headphone outputs
- Master 3 band EQ and Limiter
- Solo and Mute keys
- Aux Input for MP3 players, click tracks etc
- Built-in signal generator
- Mic stand bracket and headphone hanger included
- Mains or PoE powered
- Daisy chain or use standard PoE Ethernet hubs
Specs
| Inputs | 40 Inputs (CAT5), Stereo Aux, ambient mic |
| Outputs | 2 x stereo (Line or Headphones), mono line out |
| Control | Input: Level, Mute, Pan, Solo, Trim All Master: Level, Mute, 3-band EQ, Limiter Group: Level, Mute, Level/Pan for sources within a Group |
| Groups | 16; up to 40 sources assignable |
| Presets | 16; Store input levels, Mutes, Pans, Key assign, Names, Group sources |
| Configuration | Stores setup and all presets |
| Name | Channels, Keys, Unit, Presets, Configuration |
| Data Port | USB: Individual presets or config transfer, firmware update |
| CAT5 | Audio and PoE: Link In and Link Out, locking etherCON connectors |
| Stereo Output | Stereo 1/4" and 3.5 mm jacks Headphones: 300 mW + 300 mW into 100 Ω load < Maximum +21 dBu |
| Mono Output | Balanced TRS jack Nominal 0 dBu, maximum +18 dBu |
| AUX Input | Stereo 3.5 mm jack Nominal -8 dBu, Maximum +10 dBu Input Impedance >10 kΩ |
| AD/DA Conversion | 24-bit Delta/Sigma, 48 kHz |
| Residual Output Noise | 48 kHz -95 dBu (Level down, 20 to 20 kHz) |
| Frequency Response | +0/-1 dB, 10 Hz to 20 kHz |
| Power | Mains: 100 to 240 VAC, 50 / 60 Hz In, 12 VDC 1.25 A Out Power over CAT5 Cable (PoE): 10 W (Requires 13 W from PoE hub) |
| Dimensions (W x D x H) | 8.9 x 5.9 x 2.2" (225 x 150 x 55 mm) |
| Weight | 2.0 lb (900 g) including phones hook |
Please note that this item works with the AH-SQ-5, AH-SQ-6, AH-SQ-7, AH-QU-PAC-32, AH-QU-16C, AH-QU-24C, AH-QU-32C, AH-QU-SB, AH-AB8999, and AH-AA8705.
