Allen & Heath AH-M-DL-AES2I8O-A AES3 Card with 2 In/8 Out for dLive
AES3 I/O cards provide a convenient solution for digital patching from a dLive system to system PA, monitor amps and speaker controllers, or for console combining. Four different cards are offered to fit a wide variety of I/O requirements: 2 in / 8 out, 4 in / 6 out, 6 in / 4 out, and 10 out. The cards’ output sample rate is switchable between 96kHz, 88.2kHz, 48kHz and 44.1kHz, while the inputs provide sample rate conversion from 32kHz to 192kHz.
All AES3 cards can be fitted to any I/O Port in an Allen & Heath dLive or Avantis.
Features
- Choice of AES3 cards
- 4in 6out (M-DL-AES4I6O-A)
- 10out (M-DL-AES10O-A)
- 6in 4out (M-DL-AES6I4O-A)
- 2in 8out (M-DL-AES2I8O-A)
- Switchable sample rate (96kHz, 88.2kHz, 48kHz and 44.1kHz)
- Input SRC 32kHz to 192kHz
- Option to sync from first AES input
Other Details
Allen & Heath warrants the Allen &Heath -branded hardware product and accessories contained in the original packaging ("Allen & Heath Product”) against defects in materials and workmanship when used in accordance with Allen & Heath's user manuals, technical specifications and other Allen & Heath product published guidelines for a period of ONE (1) YEAR from the date of original purchase by the end-user purchaser ("Warranty Period"). This warranty does not apply to any non-Allen & Heath branded hardware products or any software, even if packaged or sold with Allen & Heath hardware. Please refer to the licensing agreement accompanying the software for details of your rights with respect to the use of software (“EULA”). Details of the EULA, warranty policy and other useful information can be found on the Allen & Heath website: www.allen-heath.com/legal. Repair or replacement under the terms of the warranty does not provide right to extension or renewal of the warranty period. Repair or direct replacement of the product under the terms of this warranty may be fulfilled with functionally equivalent service exchange units. This warranty is not transferable. This warranty will be the purchaser’s sole and exclusive remedy and neither Allen & Heath nor its approved service centers shall be liable for any incidental or consequential damages or breach of any express or implied warranty of this product. Conditions of Warranty The equipment has not been subject to misuse either intended or accidental, neglect, or alteration other than as described in the User Guide or Service Manual, or approved by Allen & Heath. Any necessary adjustment, alteration or repair has been carried out by an authorized Allen & Heath distributor or agent. The defective unit is to be returned carriage prepaid to the place of purchase, an authorized Allen & Heath distributor or agent with proof of purchase. Please discuss this with the distributor or the agent before shipping. If the unit is to be repaired in a different country to that of its purchase the repair may take longer than normal, whilst the warranty is confirmed and parts are sourced. Units returned should be packed in the original carton to avoid transit damage. DISCLAIMER: Allen & Heath shall not be liable for the loss of any saved/stored data in products that are either repaired or replaced. Check with your Allen & Heath distributor or agent for any additional warranty information which may apply. If further assistance is required please contact Allen & Heath Ltd. Any changes or modifications to the equipment not approved by Allen & Heath could void the compliance of the product and therefore the user’s authority to operate it.
