Product Description
ADJ WMS2 2.6mm Pixel Pitch Wall Mount Video Panel
Overview
Ideal for integration projects of all types, the WMS2 is ADJ’s highest resolution video panel to date. WMS2 boasts a 2.6mm pixel pitch delivering unparalleled vibrance and clarity with a pixel density of 147,456/m2 and a brightness of 800 NITS. WMS2 is wall mountable, or temporary hangable, with a front serviceable design in a horizontal or vertical configuration.*
Features
• Installation Method: Hang, Stack or Wall Mount
• Maintenance: Front Service
• Configuration*: Horizontal (wall mount, ground stack or hang); Vertical (wall mount only)
Specifications
• Pixel Pitch (mm): 2.6mm
• Pixel Density (dot/m2): 147,456
• LED sealing Type: SMD1515 Kinglight Cooper
• Module Size (mm x mm): 250 x 250
• Module Resolution (PX x PX): 96 x 96
• Panel Resolution (PX x PX): 384 x 192 pixels (horizontally) or 192 x 384 (vertically).
• Average Life (Hours): 50000H
Optical Ratings:
• Brightness (cd/m2): 800 NITS
• Horizontal Viewing Angle (Deg): 160°
• Vertical Viewing Angle (Deg): 140°
• Grey Scale (Bit): ≥14, CFD435
• Refresh Rate (Hz): 3840Hz
Power Supply:
• Input Voltage (V): 100-240VAC
• Max Power Dissipation (W/m²): 350
• Average Power consumption (W/m²): 140
Control System:
• Receiving Card: Novastar A8s-N
Environmental:
• Working Environment: Indoor
• Waterproof Level: IP20
• Working Temperature (℃): -20 ~ +40, (°F) -4 ~ 104
• Work humidity (RH): 10%~90%
• Storage temperature range: (℃) -40 ~ +80, (°F) -40 ~ 176
• Operation humidity (RH): 10%~90%
Weight / Dimensions:
• Cabinet Size (mm x mm): 39.3" x 19.6" / 1000 x 500mm
• Cabinet Weight: 21 lbs. / 9.5Kg
• Cabinet Thickness (mm): 1.3" / 33mm
Approvals:
• Certificates: ETL
