Product Description
ADJ Saber Spot RGBL LED Pinspot
Overview
The ADJ Saber Spot RGBL is ADJ Lighting next generation LED pinspot with a 20-Watt RGBL LED source, ACL lens for a tight 5.7-degree beam, is DMX and RDM complaint and features bullt-in color macros, color changing programs and has white color temperature presets ranging from 2000K to 9900K.
Features
• DMX and RDM Compliant
• Color Temperature Presets
• 63 Built-in Color Macros
• 13 Built-in Color Changing Programs
• 4-button Digital Display for easy navigation
• Electronic Dimming 0 – 100%
• Includes a scissor yoke to be hung, or set on the ground
Specifications
Optical:
• Light Source: 20 Watt, RGBL LED
• LED Life Expectancy: 30,000 Hrs
• Beam Angle: 5.7°
• Includes 2 interchangeable frost filter lens (10-degree & 45-degree)
• LED Refresh Rate: 3.6KHz
Connections:
• Power Input: Indoor power locking
• Power Pass through: Indoor power locking
• Control: 5-pin DMX In/Out pigtails
• With Wired Digital Communication Network
Control:
• 12 DMX Channel Modes: 3 HSI/4 RGBL/4 HSI+/5 RGBL/6 sRGBLI/6 RGBL/7 RGBL/8 RGBL/8 16bit/10 HSI/12 sRGBLI/13 RGBL
• RDM Compliant
Electrical:
• Input Voltage: 100-240V 50Hz/60Hz (Auto Sensing)
• Power draw 120V 60Hz: 16.7W, 0.243 Amps
• Power draw 230V 50Hz: 16.7W, 0.147 Amps
• Power Output Current: 1.2A (14W)
• Power Linking: 57pcs @120V, 95pcs @230V
Physical:
• Dimensions (LxWxH): 6.69” x 5.31” x 8.46" (170 x 135 x 215mm)
• Weight: 3.2 lbs / 1.45 kg.
• Black Housing
Certifications & Ratings:
• CE
• ETL (Pending)
• IP20
What’s Included:
• 1.83m Indoor locking power cord
• 2 frost filter lens (10-degree & 45-degree)
• Metal clip ring for frost filter lens
