Product Description
ADJ Encore Profile Mini WW WW LED Ellipsoidal Light
Overview
Ideal for large stage and broadcast applications, the American DJ Encore Profile Mini WW L is a 40W warm white LED ellipsoidal light with a 3000K color temperature and CRI of >98. Its 50,000-hour average life expectancy delivers a 900-lumen output with ease.
Separately available lenses adapt the beam angle to suit your specific needs. You can even project GOBO patterns using your preexisting equipment with the included "E" size holder. The Mini WW features digital dimming with variable curves and selectable modes as well as variable speed strobing. Adjustable refresh rates allow you to avoid unwanted flickering in film settings. A built-in OLED display with four control buttons allow you to control the DMX interface. Other control methods include RDM and a wired digital communication network.
Features
- Variable angle hanging bracket
- 3-channel DMX input/output
- IP20 rating, IP65 locking power input/output connectors
- Remote device management, wired digital communication network
- USB-A service port
- 4 control buttons, OLED display
- Requires separately available lens to properly project
Specifications
Light Source | 40 W Warm White LED Engine |
LED Life | 50,000 Hours (Average) |
Lumens | 900 |
CRI | >98 |
Color Temperature | 3000K |
Connectors | 1 x 5-Pin Male XLR DMX Input 1 x 5-Pin Female XLR DMX Output 1 x USB-A Service Port |
DMX | 3 Channel Modes (1/3/6) |
Power Connectors | 1 x IP65 Locking Power Input 1 x IP65 Locking Power Output |
Display | OLED Menu Display, 4 Control Buttons |
Refresh Rate | Adjustable 900-1500, 25,000 Hz |
Compatible Gobos | "E" Size |
Certifications | CE, IP20 |
Power Consumption | 45.6 W Max Power at 120 V 45.7 W Max Power at 230 V |
AC | 100 to 240 VAC, 50/60 Hz |
Power Linking | 25 pcs Max at 120 V 53 pcs Max at 230 V |
Ambient Temperature | 14 to 113°F / -10 to 45°C |
Dimensions | 10.75 x 6.03 x 5.67" / 273 x 153 x 144 mm |
Weight | 3.64 lb / 1.65 kg |
