ADJ Encore LP32 lP Wash Lighting Fixture
Overview
Lighting professionals looking for a linear bar fixture rated for outdoor use with pixel mapping functionality will be impressed with the American DJ Encore LP32IP, an IP65-rated, quad-color LED wash, blinder, and strobe fixture well suited for rental, event production, and concert production applications.
The fixture utilizes 32 20W quad-color 4-in-1 (red, green, blue, lime) LEDs that offer a huge variety of color options, including white light, a variable color temperature, and high CRI. The LEDs are organized into eight sections that can be controlled independently, allowing for pixel mapping effects. This IP65 fixture is sealed to prevent the ingress of liquid, snow, dust, and sand, making it suitable for temporary outdoor use and indoor applications where the fixture may be subject to liquid spillage or come into contact with excessive dust or dirt. The Encore LP32IP includes a 25° frost filter, a built-in bracket/floor stand, and a locking outdoor power cord.
Features
- LED: 32 20W RGBL LEDs (50,000 hr.)
- Beam angle: 11°, 25° with frost filter
- IP65 rated; protects from dust, sand, moisture, water
- All-metal construction with black housing
- Includes heavy-duty floor/mounting bracket with omega clamp receivers
- Sure-lock locking bracket system (securely locks every 10°)
- Includes magnetic removable filter frame to add a diffusion filter
- Flicker-free for film and broadcast
- Linear variable white temperature control (2700-7000K)
- Built-in antenna for WiFLY EXR wireless DMX
- OLED display with function button
Specifications
Fixture Type | LED Panel |
Light Source | 32 x Color LED - 20 W |
Light Source Life Expectancy | 50,000 Hours |
Colors | Red Green Blue Lime |
Pixel Configuration | 8 x Zones |
Photometrics | 11°: 14,630.9 fc / 157,491 Lux at 3.3' / 1 m (Full On) 585.3 fc / 6300 Lux at 16.4' / 5 m (Full On) |
Color Temperature | 2700 to 7000K |
Iris | No |
Zoom Adjustment | None |
Dimming | 16-Bit Electronic, 0 to 100% with 6 Dimmer Modes |
Operating Modes | DMX |
Macros / Programs | Color Macro |
Effects | Pulse Strobe |
Gobos | None |
Refresh Rate | 900 Hz to 25 kHz |
Control Protocols | DMX512, WiFly |
DMX Channel Modes | 10 Mode(s): 4 / 7 / 8 / 13 / 16 / 32 / 35 / 41 / 44 / 64-Channel |
Display / Controls | OLED / 4-Button |
Remote Control | None |
App Compatible | No *As of November, 2022: Check with manufacturer for the most up-to-date compatibility |
Inputs/Outputs | 1 x XLR 5-Pin DMX Input 1 x XLR 5-Pin DMX Output |
Wireless Range | WiFly: 2500' / 762 m |
AC Input Power | 100 to 240 VAC, 50/60 Hz |
AC Power Connector | Not Specified by Manufacturer |
Power / Current Consumption | 334 W |
Power Linking | 2 Units at 120 VAC 6 Units at 240 VAC |
IP Rating | IP65 |
Mounting | Floor Base, Mounting Bracket, Omega Bracket |
Included Accessories | 1 x Filter 1 x Power Cable |
Duty Cycle | None |
Exterior Color | Black |
Cooling | Fan |
Certifications | CE *as per Manufacturer |
Dimensions | 13.9 x 9.7 x 6.5" / 35.3 x 24.6 x 16.5 cm |
Weight | 24.2 lb / 11 kg |
