Product Description
ADJ ElectraPix Par 7 IP65 Rated, Battery Powered, Wireless DMX LED Fixture
Overview
The ADJ Lighting ElectraPix Par 7 is a IP65-rated, battery powered, wireless DMX LED fixture. It features seven 20-Watt Hex Color LED (RGBAL+UV), Aria X2 wireless DMX and has a battery life up to 10 hours.
Features
- 7 Pixel, Hex Color LED (RGBAL+UV) LED Par
- Battery or Wall Powered
- 5 Hour Standard Battery Operation and 10 Hour Saver Battery Operation (Menu Option)
- Individual Pixel Control
- Built-In Foreground LED Programs
- Built-In Background LED Programs
- Variable White Color Temperature Control (2,700K ~ 9,900K)
- English & Spanish User Menu
- Built-In Alarm
- Color Calibrated LED's
- User Selectable LED Refresh Rates (900Hz ~ 25K)
- 6 User Selectable Dim Modes
- 4 User Selectable Dim Curves
- Electronic Strobe (0.3Hz ~ 11Hz)
- Electronic Dimming
Included Accessories
(1) Outdoor Locking Power Cable
(1) UCIR24 Remote
(1) Gel Frame
(1) 20° Diffusion Filter
Specifications
Source:
(7) 20W Hex Color RGBAL+UV Foreground LED's
(29) 0.2W RGB Background LED's
50,000 Hour Average Life*
*May vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
Optical:
2,300K ~ 9,900K White Color Temperature Range
17° Beam Angle
45mm Lens Diameter x8
Physical:
IP65 Housing
OLED Digital display
L Track system for locking accessories / rigging
Gel Frame Holder
Adjustable, hanging / kick stand bracket
Control:
DMX512
Aria X2 Wireless DMX
Bluetooth
RDM and RDM Net Compatible
IR (Includes UCIR24 wireless remote)
(4) DMX Channel Modes (5, 6, 9, 13, 21, 24, 42, 45 & 54 Channel modes)
On-board Manual Control Mode
Primary / Secondary Mode
Connections:
5pin XLR Outdoor DMX In/Out Sockets (Must be used with STRxxx, 5pin DMX cables to create IP65 seal)
Outdoor Locking Power Sockets
Battery Charging Socket
Dimensions & Weight:
Length: 11.11” (282.1mm) Width: 9.77” (590.3mm) Height: 7.46” (189.5mm)
Weight: 15.4 lbs. (7 kg)
Power:
AC100-240V/50Hz-60Hz Input
60W Power Consumption
Link 15 pieces @120VAC or 28 pieces @ 230VAC
Battery:
Rechargeable Lithium ion
Battery Capacity: 7,000mAh
Battery Voltage: 22.2V
Charge Time: 6 Hours (To Full)
5 Hour Standard Operation at Full Output and 10 Hour Saver Mode Operation at Full Output Selectable in the menu
Battery Cycles: 500
Thermal:
Ambient Operational Temperature: -4°F to 113°F (-20°C to 45°C)
Storage Temperature: -22°F to 113°F (-30°C to 45°C)
Certifications & IP Rating:
CE
cETLus (Pending)
FCC
IP65
