Product Description
ADJ Dotz Par RGBL Fixture
Overview
Drawing on the popularity of Chip On Board (C.O.B.) LED from the Dotz Par fixture, the ADJ Lighting Dotz Par RGBL uses the latest advancements in lighting technology with a RGBL (red, green, blue, lime) C.O.B. LED for a smooth, even field, high CRI output, advanced color mixing and linear color temperature control from 2700K to 6500K.
Specifications
Source
• Light Source: 16x 3.5-Watt RGBL C.O.B. LED (4x Red, 4x Green, 4x Blue & 4x Lime)
• 20,000 Hours Rated Life
Photometric Data
• CRI: TBA
• CRI R9: TBA
• Lumens: 1250
Effects
• 35° Beam Angle
• Linear Color Temperature Control (2700K to 6500K)
• Preset Color Temperatures
• 16-Bit Fine Color Control (Red, Green, Blue & Lime)
• 64 built-in Color Macros
Control
• 4-button, DMX digital display on rear panel
• 6 Operational modes: Static Color Mode, RGBL Dimmer Mode, Program Mode, Sound Active Mode, Wireless RF and DMX Controlled
• Supports RDM (Remote Device Management)
• With Wired Digital Communication Network
• 6 selectable Dimming Modes (Standard, Stage, TV, Architectural, Theatre & Stage 2)
• 4 selectable Dim Curves (Linear, Square Inv. Squa, S-Curve)
• 1200Hz LED Refresh Rate
• LED pulse and strobe effect
• Electronic Dimming: 0 - 100%
Construction / Connections
• Plastic construction
• IEC Locking, In/Out Power connectors
• Indoor 5-pin, XLR DMX, In/Out sockets
• Scissor Yoke
Electrical Thermal
• Multi-voltage operation: AC 100-240V, 50/60Hz
• Max Power LInk: 30 @120V., 57 @230V.
• Max power consumption: 36W
• Fuse protected: T1A/250V (5*20mm)
Dimensions Weight
• Length: 5.19" (131.8mm)
• Width: 8.23" (209mm)
• Height: 8.72" (221.44mm)
• Weight: 4.41lbs. / 2kg.
Approvals / Ratings
• CE
• ETL
• CSA
• IP20
Included Accessories
- (1) Power Cord
- (1) Lens Kit
