Product Description
Audio-Technica MT830cW-TH Omnidirectional Condenser Lavalier Microphone
Terminated with locking 4-pin connector for A-T UniPak® body-pack wireless transmitters. 55" (1.4 m) cable. Beige color mic and cable. Includes windscreen and clothing clip.
Designed to be worn as a lavalier or hidden in loose clothing or in the hair, the MT830R provides high intelligibility for lecturers, stage/TV performers and singers. The mic’s wide-range capability ensures clean, accurate reproduction. It operates on phantom power only.
- Small size provides excellent yet unobtrusive sound pickup
- High intelligibility for lecturers, stage/TV performers and singers
- Wide-range capability ensures clean, accurate reproduction
- 25' (7.6 m) cable permanently attached to mic, TA3F connector at power module
- Also available as:
MT830c
MT830c-TH – same as MT830c but in "theater" color (beige)
MT830cT5
MT830cT5-TH – same as MT830cT5 but in "theater" color (beige)
MT830cW
MT830cW-TH – same as MT830cW but in "theater" color (beige)
| SPECIFICATIONS | |
| ELEMENT | Fixed-charge back plate, permanently polarized condenser |
| POLAR PATTERN | Omnidirectional |
| FREQUENCY RESPONSE | 30-20,000 Hz |
| LOW FREQUENCY ROLL-OFF | 80 Hz, 18 dB/octave |
| OPEN CIRCUIT SENSITIVITY | –37 dB (14.1 mV) re 1V at 1 Pa |
| IMPEDANCE | 200 ohms |
| MAXIMUM INPUT SOUND LEVEL | 135 dB SPL, 1 kHz at 1% T.H.D. |
| DYNAMIC RANGE (TYPICAL) | 108 dB, 1 kHz at Max SPL |
| SIGNAL-TO-NOISE RATIO | 67 dB, 1 kHz at 1 Pa |
| PHANTOM POWER REQUIREMENTS | 11-52V DC, 2 mA typical |
| SWITCH | Flat, roll-off |
| WEIGHT (MICROPHONE) | 1.3 g (0.05 oz) |
| WEIGHT (POWER MODULE) | 81 g (2.9 oz) |
| DIMENSIONS (MICROPHONE) | 15.8 mm (0.62") long, |
| DIMENSIONS (POWER MODULE) | 92.9 mm (3.66") long, |
| OUTPUT CONNECTOR | Integral 3-pin XLRM-type |
| CABLE | 7.6 m (25') long (permanently attached to microphone), 2.5 mm (0.10") diameter, 2-conductor, shielded cable with TA3F-type output connector |
| ACCESSORIES FURNISHED | AT8538 power module; clothing clip; windscreens |
| Audio-Technica CASE STYLE | M7 |
