Product Description

Audio-Technica AT8022
XY Stereo Condenser Microphone with Cables

Ideal for video camera-mount use, stereo field recording, interviews and home recording, Audio-Technica's versatile AT8022 stereo condenser offers a compact housing and the pristine sound quality of a live sound field. Its coincident capsule configuration produces an X/Y stereo image in a small housing. The microphone is supplied with two cables for use with either pro or consumer gear. It offers switchable low-frequency roll-off and the convenience of battery or phantom power. The microphone is fully RoHS-compliant - free from all substances specified in the EU directive on the reduction of hazardous substances (RoHS).

Features

• Innovative capsule configuration produces accurate stereo image in smaller housing
• Compact, lightweight design is perfect for video camera-mount use as well as for stereo field recording, interviews and home recording
• Ideal for use with handheld digital recording devices
• Operates on battery or phantom-power - for use with pro or consumer equipment
• Switchable low-frequency roll-off
• Includes two cables: one balanced (two 3-pin XLRM-type connectors at output); one unbalanced (3.5mm TRS at output)
• RoHS-compliant - free from all substances specified in the EU directive on the reduction of hazardous substances (RoHS)

Specifications

• Element: Fixed-charge back plate permanently polarized condenser
• Polar Pattern: X/Y stereo
• Frequency Response: 20-15,000 Hz
• Low Frequency Roll-Off: 80Hz, 12dB/octave
• Open Circuit Sensitivity:
  Phantom: -38dB (12.5 mV) re 1V at 1 Pa
  Battery: -38dB (12.5 mV) re 1V at 1 Pa
• Channel Balanced: <2.5 dB
• Impedance:
  Phantom: 250 ohms
  Battery: 300 ohms
• Maximum Input Sound Level:
  Phantom: 128 dB SPL, 1kHz at 1% T.H.D.
  Battery: 120 dB SPL, 1kHz at 1% T.H.D.
• Dynamic Range (Typical):
  Phantom: 109 dB, 1kHz at Max SPL
  Battery: 101 dB, 1kHz at Max SPL
• Signal-to-Noise Ratio: 75 dB, 1kHz at 1Pa
• Phantom Power Requirements: 11-52V DC, 2 mA typical (each channel)
• Battery Type: 1.5V AA/UM3
• Battery Current/Life: 0.7 mA/700 hours typical (alkaline)
• Switch: Battery On/Off; Flat, roll-off
• Weight: 8.7 oz
• Dimensions:
  7.32" long
  1.87" head diameter
  0.83" maximum body diameter
• Output Connector: Integral 5-pin XLRM-type
• Cables:
  Balanced: 6.5' long, 8 conductor, shielded, vinyl-jacketed stereo cable with 5-pin XLRF-type connector at microphone end and two 3-pin XLRM-type connectors at output end
  Unbalanced: 2' long stereo cable with 5-pin XLRF-type connector at microphone end and 3.5mm TRS connector at output end
• Accessories Furnished: AT8405a stand clamp for 5/8"-27 threaded stands; windscreen; battery; soft protective pouch
