Pathway Connectivity PWINF DIN CC 12-Channel eDIN Contact Closure (Old Part #1003)
The eDIN #1003 provides DMX512 control over twelve form-C relays, for signal level switching, in a DIN-rail mountable format. Each relay may be independently wired for normally-open (NO) or normally closed (NC) operation. Field configurable through front panel or by RDM, the #1003 has nine operating modes for maximum flexibility of use.
Pathway eDIN Contact Closure interface provides twelve DMX-controlled dry contact closures for both power and signal level switching.
Features
- DMX512 start address and operating mode may be set from front panel interface or remotely using E1.20 RDM
- DMX512-present relay (normally open or normally closed)
- Indicator LEDs for power, processor, DMX input, and relay status
- Pluggable terminal block connections accept solid or stranded wire between #26 and #16 AWG
- Normally open or normally closed wiring option for each relay
- User-adjustable trigger threshold (default to 50%)
- One DMX512-A/RDM data input connection
- One passive DMX512-A data through connection
- Suitable as pilot relay for high voltage contactors, with adequate arc protection (by others)
- Data and power easily daisy-chained between modules
- Termination switch
- User-initiated diagnostics and test modes
- Firmware field-upgradable using RDM (requires Pathway Pathport gateway and RDM utility program)
Included
- DIN tray (housing) with end caps
- 11” (280mm) x 35mm DIN rail
- Installation/Operations manual
Modes
- 12 Channel Maintained
- 12 Channel Momentary
- 12 Channel Momentary "ON"
- 6 Channel Momentary Split
- 6 Channel Maintained Split
- 12 Channel Momentary Split with Secondary "Reset"
- Chase
- Single Channel Select
- Single Channel Build
Specs
- Relays rated for minimum 100,000 operations at 2A at 30VDC
- 1500V opto-isolation between DMX input and module electronics
- 250V fault protection on DMX input
- Input operating voltage: 9-30 VDC
- 6W power consumption
- Operating conditions: 0-50°C; 10-90% relative humidity, non-condensing
- 0.70 lbs (0.316 kg)
- 3.6”W x 8.0”L x 1.5”H (91mm x 200mm x 38mm)
- Compliance
- ANSI E1.11 DMX512-A(2008)/USITT DMX512(1990)
- ANSI E1.20 RDM(2010) - Remote Device Management
- RoHS 2011/65/EU
- Class 2 Low Voltage
