The SR617D Smart Remote is the desktop version of the DMX Master Remote and DMX Recorder. It is designed to provide standalone DMX scene storage and recall for DMX scenes, directly connected simple contact switches, and Lightronics Unity Architectural Lighting System stations. With its versatile usability, it is a powerful solution for repairs and upgrades of existing installations, as well as new installations looking for compact universal DMX control. With up to 16 programmable push button scenes (8 Scenes in 2 banks) it can be used in any number of applications including as a portable console, emergency controls in a booth, direct access controls backstage, etc.! The SR617D Smart Remote is ideal for churches and houses of worship, schools, theaters, conference centers, and multi-purpose facilities looking for portable master DMX control.

The SR617D provides independent control of up to 512 DMX channels while allowing users to store and recall up to 16 custom lighting scenes. Scenes may be directly captured from an incoming DMX source using snapshot functionality. 8 pushbuttons and 2 banks provide immediate access to stored scenes, making the controller suitable for everyday operation of both DMX and architectural lighting environments.

Designed to operate either as a standalone remote or as part of a larger DMX network, the SR617D can be connected inline with another DMX controller to provide supplemental scene playback and backup control capabilities. The controller supports user-defined fade times for pushbutton scenes and allows fixed DMX output values to be assigned for channel parking applications.

As part of the Lightronics Unity Architectural Lighting System, the SR617D can interface with compatible Unity control stations to provide additional lighting control locations throughout a facility. This allows lighting scenes to be recalled from multiple locations while maintaining centralized scene management and programming.

Designed for desktop applications, the SR617D provides a practical solution for facilities requiring simple, reliable architectural control of DMX-512 lighting systems. Its combination of standalone scene storage and Unity integration makes it suitable for LED and conventional lighting applications as either a primary remote or a backup to larger lighting consoles.

Features

Stores and recalls up to 16 user-defined push-button scenes on the unit.
8 pushbuttons with 2 banks
Operates as a standalone DMX controller
DMX snapshot recording capability
DMX input and DMX output operation
User-defined fade times from 0 to 55 seconds for pushbutton scenes
Programmable fixed DMX output values for channel parking
Compatible with Lightronics Unity Architectural System button control stations only
Non-volatile scene memory
Desktop enclosure
Supports LED and conventional lighting systems

Specifications

Weight	1.75 lbs
Dimensions	7 × 5 × 2.25 in
Communication Protocol	DMX-512, Unity Architectural Lighting Enabled (LitNet)
Input Power Type	12VDC 2A Power Supply
Programmable Scenes	16 Programmable Scenes
Unity Architectural Lighting Enabled (LitNet)	Yes
Mount Type	Desktop/Portable
UL-Listing	N/A
Input Communication Type	5-Pin DMX, Bidirectional RS-485 Signal from Unity System
Wall Plate / Desktop / Portable Unit Color	White
Operation Type	Push Button

Other Details

All Lightronics products are warranted for a period of TWO/FIVE YEARS from the date of purchase against defects in materials and workmanship. This warranty is subject to the following restrictions and conditions: A) If service is required, you may be asked to provide proof of purchase from an authorized Lightronics dealer. B) The FIVE YEAR WARRANTY is only valid if the warranty card is returned to Lightronics accompanied with a copy of the original receipt of purchase within 30 DAYS of the purchase date, if not then the TWO YEAR WARRANTY applies. Warranty is valid only for the original purchaser of the unit. C) This warranty does not apply to damage resulting from abuse, misuse, accidents, shipping, and repairs or modifications by anyone other than an authorized Lightronics service representative. D) This warranty is void if the serial number is removed, altered or defaced. E) This warranty does not cover loss or damage, direct or indirect arising from the use or inability to use this product. F) Lightronics reserves the right to make any changes, modifications, or updates as deemed appropriate by Lightronics to products returned for service. Such changes may be made without prior notification to the user and without incurring any responsibility or liability for modifications or changes to equipment previously supplied. Lightronics is not responsible for supplying new equipment in accordance with any earlier specifications. G) This warranty is the only warranty either expressed, implied, or statutory, upon which the equipment is purchased. No representatives, dealers or any of their agents are authorized to make any warranties, guarantees, or representations other than expressly stated herein. H) This warranty does not cover the cost of shipping products to or from Lightronics for service. I) Lightronics Inc. reserves the right to make changes as deemed necessary to this warranty without prior notification.
