Product Description
ETC CSFRESVMV ColorSource Fresnel V
G E N E R A L I N F O R M A T I O N
An LED luminaire crafted by lighting experts with a proven history of quality fixtures, ColorSource Fresnel V brings a richness of color,
increased brightness, and leading technology at a price point you’ll love. Featuring a five-color array of red, green, blue, indigo, and lime, the
ColorSource Fresnel V provides soft pastels and bold saturated colors from a single fixture. Control the motorized 13°–44° zoom using DMX
or manually from the rear of the fixture. ColorSource Fresnel V also features wireless DMX/RDM control using Multiverse® technology, NFC
configuration from your mobile device, and next level brightness, making it the ultimate in affordable wash light technology.
FEATURES
• Five-color array (red, green, blue, indigo, and lime)
• Motorized 13–44 degree zoom with DMX and local control
• Simple user interface with seven-segment display
• powerCON® TRUE1® TOP connector
• DMX/RDM in and thru (5-pin XLR)
• Multiverse wireless DMX/RDM
• NFC (near field communication) configuration
• LED droop compensation
• Optically calibrated
• Tour-ready, aluminum housing
APPLICATIONS
• Theatres and performance spaces
• Houses of worship
• Universities and schools
• Hospitality
• Retail
• Exhibition centers
• Meeting rooms
• Clubs
• Cafetoriums
O R D E R I N G I N F O R M A T I O N
ColorSource Fresnel V
Model Description ETL Part Number CE Part Number
CSFRESVMV ColorSource Fresnel V LED Fixture, black 7417A1011 7417A1211
Color options: -1 = white, -5 = silver gray, -8 = custom colors.
Also available without Multiverse wireless control. Contact your dealer for ordering information.
Classic features. Modern technology.
Fresnels have been known for their smooth wash since the beginning of time. Their adjustable zoom, barndoor accessories, and overall brightness make them an instant favorite for stages of every size and shape.
ColorSource Fresnel V combines the best features of original incandescent Fresnels with modern technology at an affordable price.
COLOR
The five-color array includes red, green, blue, indigo, and lime. Get bold saturated colors like indigos and reds, and soft pastels for beautiful skin tone rendering - all from a single array.
CONNECTOR
powerCON True1 TOP connector for secure connection that can be detached while under load.
WIRELESS
Go completely wireless with Multiverse® and gain up to 10 universes of wireless DMX/RDM control. Scale your wireless systems like you never thought possible!
BRIGHTNESS
Next level brightness without sacrificing high-quality color.
MOBILE CONFIGURATION
NFC configuration from your mobile device when used with ETC’s free Set Light app. Set the fixture properties, even if the fixture isn’t powered on. This means fixture hang and configuration just got more efficient!
Color integrity
13-44 degree zoom
Fresnel V has motorized zoom control, both via DMX or manually from the back of the fixture. With a 13-44° zoom range, you can seamlessly use Fresnel V as part of a wash in one scene and a beamy special in the next.
A Fresnel is only as good as its performance with barndoors, and Fresnel V delivers with smooth fall off and clean edges.
Lower Watts
Lower watts for more output means lower power consumption and increased luminaires per circuit. But, perhaps just as importantly, it means lower heat, which leads to quieter fans and quieter fixtures overall. ETC obsesses over every detail, ensuring that the fixture you buy today will still be lighting incredible shows for years to come.
Long, light life
The entire ColorSource Fresnel V fixture has an L70 rating of 54,000 hours. To put that in perspective, with an average per-day usage of three hours, seven days a week, you are looking at a lifespan of 50 years from one single fixture.
You’ll feel confident in ColorSource V lighting your stage for a long time to come.
PRODUCT SPECIFICATIONS
